EXHAUST MUFFLER 🏍️ XR250R
STEP 🏍️ XR250R

PEDAL/KICK STARTER ARM for XR250R SHASTA WHITE (NH138H) from 1993

PEDAL/KICK STARTER ARM for XR250R SHASTA WHITE (NH138H) from 1993
Reference
Product name
#2 28241-KT1-671

JOINT, KICK ARM

Price €76.44
Contact us
#3 28300-KT1-671

ARM ASSY, KICK STARTER

Price €199.32
#4 28333-KK0-000

SPRING, KICK STARTER

Price €5.57
#5 35350-KN5-651 i

SWITCH ASSY, RR STOP

Price €32.03
Contact us
#6 35357-ME9-000 i

SPRING, STOP SWITCH

Price €7.06
#7 46500-KZ9-000

PEDAL COMP, RR BRAKE

Contact us
#8 46514-KZ9-000

SPRING, BRAKE PEDAL

Price €10.02
#9 46515-MN1-670

TUBE, BRAKE PEDAL SPRING

Price €6.56
#10 46525-KK0-003 i

DUST SEAL, 17X20X25

Price €5.63
#11 46526-KZ9-000

COVER, MIDDLE ARM

Contact us
#12 50530-KT1-770

BAR, SIDE STAND

Contact us
#13 50535-KN5-670 i

SPRING, SIDE STAND

Price €12.46
#17 90101-KT1-780

BOLT, KICK ARM

Contact us
#18 95701-0602007 i

BOLT, FLANGE, 6X20

Price €1.15
#19 90108-KG0-000 i

SCREW, SIDE STAND PIVOT

Price €13.22
#21 90304-GE8-003 i

NUT, U, 10MM (FUSE RASHI)

Price €6.92
#24 90650-KV6-003 i

BAND, WIRE, 95MM

Price €9.46
#26 96211-08000 i

BALL, STEEL, 8 (1/4)

Price €0.46
#27 96300-0802507 i

BOLT, FLANGE, 8X25

Price €1.96
#1 24700-KZ1-600

PEDAL ASSY, CHANGE

Contact us
# 18231-KK0-000

JOINT, EX PIPE

Price €27.74
Contact us
# 18233-437-000

COLLAR, EX PIPE JOINT

Price €14.90
# 18291-KZ1-670

GASKET, EX PIPE

Price €7.55
# 18292-KBR-000 i

PACKING, PROTECTOR

Price €4.80
# 18293-GE8-000 i

RUBBER, PROTECTOR PACKING

Price €7.60
# 18295-KZ1-670 i

PACKING B, MUFFLER

Price €11.78
# 18310-KZ1-671 i

MUFFLER COMP

Contact us
# 18311-KT0-670

PIPE COMP, TAIL

Price €44.66
Contact us
# 18315-KZ9-000

PLATE, HEAT GUARD

Contact us
# 18320-KT1-670

PIPE COMP, EX

Contact us
# 18325-KK0-000

PROTECTOR, EX PIPE

Contact us
# 18373-429-010

LID, MUFFLER

Price €13.73
# 18374-MN1-880

PACKING, MUFFLER LID

Price €7.01
# 18376-KG0-003

BAND, MUFFLER

Price €41.16
# 18392-MK4-000 i

PACKING, MUFFLER

Price €17.09
# 90304-438-000 i

NUT, CAP, 6MM

Price €11.29
# 93401-0601207 i

BOLT-WASHER, 6X12

Price €0.96
# 94101-06700

WASHER, PLAIN, 6MM

Price €0.78
# 96001-0601007 i

BOLT, FLANGE, 6X10

Price €1.08
# 96001-0601207 i

BOLT, FLANGE, 6X12

Price €1.25
# 96300-0802200 i

BOLT, FLANGE, 8X22

Price €1.74
# 96300-0804007

BOLT, FLANGE, 8X40

Price €1.98
# 96300-1002000 i

BOLT, FLANGE, 10X20

Price €2.09
