OIL COOLER (XR250RG/RH/RJ/RK/RL/RM) for XR250R SHASTA WHITE (NH138) from 1991

OIL COOLER (XR250RG/RH/RJ/RK/RL/RM) for XR250R SHASTA WHITE (NH138) from 1991
Reference
Product name
#1 15510-KT1-900

PIPE COMP, R OIL HOSE

Contact us
#2 15516-KT1-671

BOLT A, OIL HOSE

Price €11.93
Contact us
#3 15520-KT1-900

PIPE COMP, L OIL HOSE

Contact us
#4 15600-KT1-672

COOLER COMP, OIL

Contact us
#5 15602-KT1-670

RUBBER, HOOK

Price €13.00
Contact us
#6 15603-KT1-670

RUBBER, OIL PIPE

Price €9.37
#7 15604-KT1-670

WASHER, OIL COOLER

Contact us
#8 15630-KT1-900

PLATE, OIL HOSE SETTING

Contact us
#10 34931-KT1-670

RUBBER, OIL COOLER

Price €8.08
#11 90016-ZA5-000

NUT, SPECIAL, 5MM

Price €2.63
#12 90113-GE8-000

SCREW, HANDLE LEVER PIVOT

Price €8.05
#13 90503-KE1-000

COLLAR, 63X135

Price €8.00
#14 91301-KF0-000

GASKET, RUBBER, 98MM

Price €6.50
#15 94101-06000 i

WASHER, PLAIN, 6MM

Price €0.82
#16 94109-14000

WASHER, DRAIN PLUG, 14MM

Price €1.78
#17 96001-0601407 i

BOLT, FLANGE, 6X14

Price €1.34
#18 96001-0602007 i

BOLT, FLANGE, 6X20

Price €1.42
#19 96500-0602200 i

BOLT, FLANGE, 6X22

Price €1.66
#9 15711-KT1-670

CLAMPER, OIL PIPE

Contact us
