PEDAL/KICK STARTER ARM for XR250R FLASH RED (R119) from 1984

PEDAL/KICK STARTER ARM for XR250R FLASH RED (R119) from 1984
Reference
Product name
#4 28333-KK0-000

RESSORT DE KICK DE DEMARRAGE

Price €5.57
#9 43459-434-000 i

NUT OF ADJUSTMENT OF BRAKE

Price €18.08
#14 46525-KK0-003 i

COVER-POUSSIERE, 17X20X2.5

Price €5.63
#19 50535-429-000 i

SIDE STAND SPRING

Price €12.46
#24 90101-329-000

BOLT, KICK ARM

Price €7.67
#25 90108-KG0-000 i

SCREW, SIDE STAND PIVOT

Price €13.22
#27 90304-GE8-003 i

U-NUT, 10MM (FUSE RASHI)

Price €6.92
#30 90683-KJ2-003 i

CLIP OF ELECTRIC HARNESS

Price €9.12
#31 92225-060250A i

BOLT, HEX, 6X25

Contact us
#32 94001-060000S i

NUT HEX., 6MM

Price €1.19
#33 94201-16150 i

SPLIT PIN, 1.6X15

Price €0.78
#34 95014-73100 i

SPRING A OF ROD OF BRAKE

Price €1.50
#35 95015-52000 i

PIN B, BRAKE ROD JOINT

Price €3.00
#37 95700-0802500 i

BOLT, FLANGE, 8X25

Price €1.61
#38 96000-0602000 i

FLANGE BOLT, 6X20

Price €1.25
#39 96211-08000 i

STEEL BALL, 8 (1/4)

Price €0.46
#1 24700-KK1-620

PEDAL COMP, GEAR CHANGE

Contact us
#2 28241-KK0-300

JOINT, KICK ARM

Contact us
#3 28300-KK0-000

ARM ASSY, KICK STARTER

Contact us
#5 35350-MG2-000

SWITCH ASSY, RR STOP

Contact us
#6 35357-KK0-650

SPRING, STOP SWITCH

Contact us
#7 43451-KK0-000

ROD, RR BRAKE

Contact us
#8 43454-MA0-000

PLATE, BRAKE CABLE FIXING

Contact us
#10 46500-KK0-000

PEDAL ASSY, BRAKE

Contact us
#12 46511-KK0-000 i

SPRING, BRAKE PEDAL

Price €14.69
Contact us
#17 50134-KK0-650ZA

STAY, STOP SWITCH R119 (R119 FLASH RED)

Contact us
#18 50530-KK0-000

BAR, SIDE STAND

Contact us
#23 90101-KK0-000

SHAFT, RR BRAKE PIVOT

Price €30.24
#26 90124-KK4-000

BOLT, FLANGE, 8X25

Price €6.32
