METER/HORN/KEY SET (EXCEPT XL125S-CM) for XL125S MONZA RED (R110) from 1979

METER/HORN/KEY SET (EXCEPT XL125S-CM) for XL125S MONZA RED (R110) from 1979
Reference
Product name
#1 17245-107-010 i

RUBBER, AIR CLEANER CASE MOUNTING

Price €10.15
#7 34902-202-000 i

BULB, DASH (6V 3W)

Price €5.54
#8 34908-230-000

BULB, SPEEDOMETER (6V 17W)

Price €6.50
#9 35010-437-620

KEY SET

Contact us
#10 35100-437-007 i

SWITCH ASSY, COMBINATION

Price €156.29
#11 35114-437-000

PROTECTOR, CORD

Contact us
#11 35114-437-010

PROTECTOR, CORD

Contact us
#15 37200-437-621 i

SPEEDOMETER ASSY (KPH)

Price €514.02
Contact us
#16 37210-437-000

RUBBER, METER CUSHION

Price €12.92
#19 37245-437-008

STAY, METER

Contact us
#20 37250-437-621

TACHOMETER ASSY

Contact us
#21 37260-437-000 i

CABLE ASSY, TACHOMETER

Price €45.35
Contact us
#22 37261-437-000 i

CABLE, INNER

Price €25.87
Contact us
#23 37610-437-008

CASE, PILOT UPPER

Price €157.81
#24 37618-437-008

CASE, PILOT LOWER

Price €70.76
#25 37619-437-008

CORD COMP, PILOT

Contact us
#27 38110-428-601

HORN COMP

Contact us
#28 44830-437-000 i

CABLE ASSY, SPEEDOMETER

Price €50.93
Contact us
#29 44831-437-000 i

CABLE, INNER ()

Price €18.28
Contact us
#30 61104-428-010 i

COLLAR, FR FENDER (WHITE)

Price €12.07
#30 61104-428-730

COLLAR, FR FENDER (BLACK)

Price €12.07
#32 61312-358-300

GROMMET, HEADLIGHT CASE

Price €12.05
#33 61316-361-000

RUBBER, BRACKET MOUNTING

Price €16.63
#34 80109-367-690 i

COLLAR C63, MOUNTING

Price €13.67
#35 91351-121-710

O-RING

Contact us
#36 92000-06025 i

BOLT, HEX, 6X25

Price €1.19
#37 93901-24210

SCREW, TAPPING, 4X10

Price €0.64
#38 93903-24780

SCREW, TAPPING, 4X30

Price €0.78
#39 94021-06070 i

NUT, CAP, 6MM

Price €1.78
#41 94111-06700

WASHER, SPRING, 6MM

Price €0.64
#44 95700-0801200 i

BOLT, FLANGE, 8X12

Price €1.25
