REAR WHEEL/SWINGARM for PCX 125 PEARL SPLENDOR RED (R369) from 2019

REAR WHEEL/SWINGARM for PCX 125 PEARL SPLENDOR RED (R369) from 2019
Reference
Product name
#1 06430-KWN-900

SHOE SET, BRAKE (JB)

Price €41.53
#2 11203-K35-J00

BUSH, RR CUSHION UNDER RUBBER

Price €5.45
#2 11203-KVB-901

BUSH, RR CUSHION UNDER RUBBER (HOKUSHIN)

Price €8.96
#3 42311-K96-V00

COLLAR, RR WHEEL SIDE

Price €8.22
#4 42312-KWN-700

COLLAR B, RR WHEEL SIDE

Price €5.82
#5 42650-K97-T00ZA

WHEEL SUB ASSY, RR NH303M (NH303M MAT AXIS GRAY...

Price €467.53
#6 42711-K97-T01 i

TIRE, RR (MICHELIN) (120/70-14 M/C 61P)

Price €491.00
#6 42711-K97-T03 i

TIRE, RR (MICHELIN) (120/70-14 M/C 61P)

Price €491.00
#7 42753-GM9-743 i

VALVE OF RIM (IRC)

Price €18.61
#7 42753-KBS-901 i

VALVE, RIM (WONDER)

Price €2.89
#7 42753-KWF-901 i

VALVE, RIM (TRITON)

Price €6.80
#8 43141-KVB-900

CAM, RR BRAKE

Price €14.36
#9 43151-329-000 i

SPRING OF MACHOIRES OF BRAKE

Price €7.45
#10 43410-K97-T00

ARM COMP, RR BRAKE

Price €23.20
#11 43459-GN5-760 i

NUT, BRAKE ROD ADJUSTING

Price €3.00
#12 43472-K97-T00

SPRING, RR BRAKE ARM

Price €1.76
#13 52100-K96-D00

SWINGARM ASSY, RR

Price €441.66
#14 90112-K97-T00

BOLT, FLANGE, 6X35

Price €1.68
#15 90305-KWN-701

U-NUT, 16MM

Price €9.14
#16 90651-KZR-601

CIRCLIP, INTERNAL, 40MM (TOPY FASTENERS)

Price €3.97
#16 94520-40000

CIRCLIP, INTERNAL, 40MM

Price €2.08
#17 91051-K35-V01 i

BEARING, RADIAL BALL, 6203UU L (NSK)

Price €16.61
#17 91051-K35-V02 i

BEARING, RADIAL BALL, 6203UU L (NTN)

Price €16.61
#17 91051-K35-V03 i

BEARING, RADIAL BALL, 6203UU L (FUJIKOSHI)

Price €16.61
#17 91051-K35-V04 i

BEARING, RADIAL BALL, 6203UU (FAG)

Price €16.61
#18 91252-K35-V01

COVER-POUSSIERE, 25X40X5

Price €2.51
#19 91253-K35-V01

DUST SEAL, 25X35X6

Price €2.51
#20 94101-10000

PLAIN WASHER, 10MM

Price €0.88
#21 95015-32001 i

BRAKE ARM CONNECTOR B

Price €1.50
#22 95701-1004000 i

BOLT, FLANGE, 10X40

Price €1.92
