AIR CLEANER 🏍️ VFR800X
PEDAL 🏍️ VFR800X

PEDAL for VFR800X MAT BULLET SILVER (NH389) from 2013

PEDAL for VFR800X MAT BULLET SILVER (NH389) from 2013
Reference
Product name
#2 24781-KR3-770

RUBBER, GEAR CHANGE PEDAL

Price €9.32
#3 35350-MGY-D21

SWITCH ASSY, RR STOP

Price €44.60
#4 35357-MBR-000

SPRING, STOP SWITCH

Price €6.34
#5 46500-MGY-D20

PEDAL COMP, RR BRAKE

Price €177.96
#7 90557-230-000

WASHER, 152X25

Price €6.56
#8 90601-KAF-003

CLIP, SWITCH COVER

Price €4.34
#9 90683-KJ2-003

CLIP, WIRE HARNESS

Price €9.28
#10 94511-15000

CIRCLIP, EXTERNAL, 15MM

Price €0.91
#12 24705-MGY-D20

PEDAL COMP, GEAR CHANGE

Price €125.74
#13 24710-MGY-D20

ARM COMP, CHANGE

Price €107.70
#14 24724-MBW-D21

COVER, DUST

Price €19.44
#15 46511-MGY-D20

SPRING, BRAKE PEDAL

Price €16.99
#16 90010-ML0-720

BOLT, FLANGE, 6X20

Price €6.37
#17 90113-MCF-000

BOLT, CHANGE PIVOT

Price €12.73
#18 90165-MGY-D20

BOLT, TIE ROD

Price €13.03
#19 90201-700-000

NUT, GOVERNOR ARM FIXING (LEFT HAND THREAD)

Price €0.85
#20 90505-MBW-000

WASHER, CHANGE PEDAL WAVE

Price €5.17
#21 94002-060200S

NUT, HEX, 6MM

Price €0.97
#22 94103-08000

WASHER, PLAIN, 8MM

Price €0.78
