CYLINDER HEAD (FRONT) for VFR800F VICTORY RED (R334) from 2014

CYLINDER HEAD (FRONT) for VFR800F VICTORY RED (R334) from 2014
Reference
Product name
#1 12010-MJM-D00

HEAD ASSY, FR CYLINDER

Price €2,733.92
#2 12204-MCW-305

GUIDE A, VALVE (OS)

Price €35.84
#3 12205-MCW-305

GUIDE B, VALVE (OS)

Price €37.87
#4 12217-MBG-000

COLLAR, 25MM

Price €15.96
#5 12217-MCE-000

BOLT, ORIFICE

Price €6.53
#6 12251-MCW-013

GASKET, FR CYLINDER HEAD

Price €109.18
#7 12396-MBG-000

GASKET C, HEAD COVER

Price €9.23
#8 16211-MCW-D00

INSULATOR, THROTTLE BODY

Price €33.84
#9 16217-MJM-D00

BAND, INSULATOR

Price €16.79
#10 16218-MCW-000

BAND B, INSULATOR

Price €14.84
#11 16222-MV4-300

NUT, SQUARE, 5MM

Price €4.88
#12 31911-HW1-671

PLUG, SPARK (IMR9D-9H) (NGK)

Price €39.20
#12 31912-HW1-671

PLUG, SPARK (VNH27ZB) (DENSO)

Price €72.86
#13 37870-MBG-003 i

SENSOR ASSY, WATER TEMPERATURE

Price €98.24
#14 90002-MCW-000

BOLT, FLANGE, 6X45

Price €5.46
#15 90005-MAS-E00

BOLT, RECESSED, 5X28

Price €5.46
#16 90005-MM4-000

BOLT, RECESSED, 5X32

Price €2.83
#17 90006-GHB-780

BOLT, FLANGE, 6X75 (NSHF)

Price €5.96
#18 90007-MCW-000

BOLT-WASHER, 9X100

Price €11.74
#19 90016-KT7-000

BOLT, FLANGE, 6X37

Price €5.21
#20 90035-MW4-000

BOLT, STUD, 6X22

Price €4.57
#21 90454-MC7-000

WASHER, SPECIAL, 12MM

Price €5.99
#22 90463-ML7-000 i

WASHER, SEALING, 65MM

Price €4.62
#23 91307-PY4-003 i

O-RING, 245X19

Price €4.72
#24 91317-P4V-004

O-RING, 98X19 (ARAI)

Price €4.37
#25 94301-08140 i

DOWEL PIN, 8X14

Price €2.05
#26 94301-10160 i

DOWEL PIN, 10X16

Price €2.38
#27 94301-12200 i

DOWEL PIN, 12X20

Price €2.08
