TRANSMISSION (VFR1200XD/XDA/XDL/XDS) (COUNTERSHAFT) for VFR1200X Dual Clutch MAT TITANIUM BLADE METALLIC (YR327) from 2014

TRANSMISSION (VFR1200XD/XDA/XDL/XDS) (COUNTERSHAFT) for VFR1200X Dual Clutch MAT TITANIUM BLADE METALLIC (YR327) from 2014
Reference
Product name
#1 23221-MGE-D00

COUNTERSHAFT

Price €357.23
#2 23421-MGH-D20

GEAR, COUNTERSHAFT FIRST (36T)

Price €280.37
#3 23441-MGE-J00

GEAR, COUNTERSHAFT SECOND (34T)

Price €264.16
#4 23461-MGE-J00

GEAR, COUNTERSHAFT THIRD (30T)

Price €259.39
#5 23462-MAT-000

COLLAR, SPLINE, 30X11

Price €31.80
#6 23481-MGH-D20

GEAR, COUNTERSHAFT FOURTH (31T)

Price €258.76
#7 23493-MGE-D00

COLLAR, 30X33X128

Price €31.57
#8 23501-MGH-D20

GEAR, COUNTERSHAFT FIFTH (29T)

Price €298.08
#9 23521-MGH-D20

GEAR, COUNTERSHAFT SIXTH (31T)

Price €292.44
#10 23530-MGH-D20

GEAR COMP, FINAL DRIVE (41T)

Price €597.31
#11 23545-MGE-000

COTTER, COUNTERSHAFT

Price €17.39
#12 90037-ME9-000

BOLT, SPECIAL, 10MM

Price €10.36
#13 90402-MGE-010

RETAINER, COUNTERSHAFT

Price €18.04
#14 90407-415-000 i

WASHER, THRUST, 26MM

Price €13.06
#15 90412-MGE-000

WASHER, 105X318X32

Price €12.56
#16 90452-MAT-000

WASHER, SPLINE, 30X36X15

Price €6.26
#17 90455-ML7-000 i

WASHER B, THRUST, 22MM (BLUE)

Price €7.87
#18 90463-MAT-000

WASHER, SPLINE, 30MM

Price €7.87
#19 90464-MAT-000

WASHER, LOCK, 30MM

Price €11.33
#20 90601-MA6-000

RING, BEARING SETTING, 56MM

Price €7.91
#21 90603-MN4-000 i

CIRCLIP, 28MM

Price €7.63
#22 90604-MM5-000

CIRCLIP, 30MM

Price €10.96
#23 91001-MCH-003 i

BEARING, NEEDLE, 26X30X13

Price €34.98
#24 91003-MGE-003

BEARING, SPECIAL BALL, 22X56X215

Price €66.84
#25 91025-MBT-F21

BEARING, NEEDLE, 22X38X193

Price €78.64
