SIDE GEAR CASE for VFR1200X Dual Clutch CANDY PROMINENCE RED (R342) from 2017

SIDE GEAR CASE for VFR1200X Dual Clutch CANDY PROMINENCE RED (R342) from 2017
Reference
Product name
#1 11663-MGE-003

GASKET, SIDE GEAR CASE

Price €28.50
#3 21100-MGE-D00

CASE ASSY, SIDE GEAR

Price €2,217.46
#5 23541-MGE-D00

GEAR, FINAL DRIVEN (39T)

Price €266.18
#6 23733-MGE-000

COLLAR, 25X30X286

Price €43.40
#7 32156-MGE-D01

STAY, HARNESS CLIP

Price €16.49
#9 90005-MGE-010

BOLT, FLANGE, 8X95

Price €12.00
#10 90006-MGE-010

BOLT, UBS, 8X40

Price €12.44
#11 90016-GHB-680

BOLT, FLANGE, 6X28

Price €7.06
#12 90016-GHB-700

BOLT, FLANGE, 6X35

Price €7.06
#13 90016-GHB-760

BOLT, FLANGE, 6X65

Price €7.38
#14 90037-ME9-000

BOLT, SPECIAL, 10MM

Price €8.89
#15 90403-MGE-000

WASHER, SPECIAL, 25X404X12

Price €12.82
#16 90414-MGE-D00

WASHER, 105X36X4

Price €11.16
#17 90441-706-000

WASHER, SEALING, 6MM

Price €1.00
#18 90442-028-000

WASHER, SEALING, 8MM

Price €3.34
#20 91005-MGE-003

BEARING, BALL, 6305

Price €38.30
#22 91205-MGE-003

OIL SEAL, 28X66X8

Price €19.07
#24 94302-10120

DOWEL PIN, 10X12

Price €2.72
#25 94520-65120

CIRCLIP, INTERNAL, 65MM

Price €3.77
