THROTTLE BODY for Dax ST125 PEARL GLITTERING BLUE (B231) from 2023

THROTTLE BODY for Dax ST125 PEARL GLITTERING BLUE (B231) from 2023
Reference
Product name
#1 16016-K03-H11

SET DE SCREW

Price €6.12
#2 16075-KYZ-711

O-RING

Price €7.39
#3 16077-KVB-S51

GASKET TORIQUE, 1.9X20.4

Price €5.46
#4 16081-KPH-701 i

SCREW OF CLAMP 5X8.7

Price €7.08
#5 16157-K2W-D10

COVER COMP, THROTTLE BODY R

Price €21.91
#6 16158-K2W-D10

COVER COMP, THROTTLE BODY L

Price €16.07
#7 16169-K46-N21

STAY, WIRE

Price €27.38
#8 16400-K2W-D11

BODY ASSY, THROTTLE (GQY2C A)

Price €97.33
#9 16410-K2W-D11

BODY SET

Price €65.51
#10 16450-K76-T61

INJECTOR ASSY, FUEL

Price €70.74
#11 16472-KPC-D50

RING OF GASKET

Price €6.80
#12 16480-KVB-S51

SOLENOIDE

Price €73.50
#13 16485-GGZ-J01

SEAT SET

Price €13.81
#14 17120-K2W-D10

STAY COMP, THROTTLE BODY COVER

Price €29.14
#15 17560-K26-G00

JOINT COMP, INJECTOR

Price €50.76
#16 90114-KPH-700

VIS SPECIALE, 5X11

Price €3.97
#17 90116-K0A-E11

RIVET, TAPPET 6MM

Price €7.63
#18 91301-GGL-J01

O-RING, 6.3X2.2

Price €21.91
#19 93414-0502508

BOLT-WASHER, 5X25

Price €1.61
#20 93892-0501218 i

SCREW A HEAD A WASHER, 5X12

Price €1.34
#21 95801-0602200 i

BOLT, FLANGE, 6X22

Price €1.42
#22 96001-0602000 i

FLANGE BOLT, 6X20

Price €1.25
