TRANSMISSION for Shadow Aero NOIR (NH1X) from 2001

TRANSMISSION for Shadow Aero NOIR (NH1X) from 2001
Reference
Product name
#1 15520-MS6-000

PIPE COMP, OIL FEED

Price €23.21
#2 23210-MBA-000

MAINSHAFT COMP (12T)

Price €181.39
#3 23212-MS6-920

PLATE, BEARING SETTING

Price €17.86
#4 23220-MBA-000

SHAFT, COUNTER

Price €180.05
#5 23421-MBA-000

GEAR, COUNTERSHAFT FIRST (38T)

Price €208.51
#6 23422-MV1-000

COLLAR, SPLINE, 28X10

Price €18.18
#7 23431-MBA-000

GEAR, MAINSHAFT SECOND (17T)

Price €55.46
#8 23441-MBA-000

GEAR, COUNTERSHAFT SECOND (34T)

Price €137.80
#9 23442-MR5-670

BUSH, 28X31X10

Price €24.26
#10 23451-MY1-000

GEAR, MAINSHAFT THIRD (20T)

Price €152.12
#11 23455-MS9-750

BUSH, 25X28X135

Price €27.34
#12 23461-MBA-000

GEAR, COUNTERSHAFT THIRD (30T)

Price €208.51
#13 23471-MBA-000

GEAR, MAINSHAFT FOURTH (23T)

Price €147.68
#14 23481-MBA-000

GEAR, COUNTERSHAFT FOURTH (27T)

Price €138.18
#15 23482-MR7-000

COLLAR, SPLINE, 28X135

Price €22.13
#16 23491-MBA-000

GEAR, MAINSHAFT FIFTH (24T)

Price €173.28
#17 23501-MBA-000

GEAR, COUNTERSHAFT FIFTH (25T)

Price €196.06
#18 23512-MR7-000

COLLAR, SPLINE, 25X16

Price €21.92
#19 23801-MBA-000

SPROCKET, DRIVE (17T)

Price €71.87
#20 23811-MV1-000

PLATE, FIXING

Price €17.29
#21 90118-958-003

BOLT, FLANGE, 6X12

Price €7.38
#22 90404-KK0-000

WASHER, 20X37X2

Price €5.34
#23 90451-KY2-000

WASHER, SPLINE, 25X31X15

Price €5.34
#24 90452-MR7-000

WASHER, SPLINE, 28X34X15

Price €5.57
#25 90456-MA6-000

WASHER, THRUST, 25MM

Price €3.02
#26 90463-MR7-000

WASHER, SPLINE, 28MM

Price €10.72
#27 90464-MR7-000

WASHER, LOCK, 28MM

Price €10.57
#28 90601-107-000

CIRCLIP, 25MM

Price €5.35
#29 90603-MN4-000

CIRCLIP, 28MM

Price €7.90
#30 91001-MN5-003

BEARING, BALL, 28X54X206 (NTN)

Price €40.99
#31 91001-MV1-003

BEARING, RADIAL BALL, 62/25

Price €40.99
#32 91003-MG2-792

BEARING, RADIAL BALL, 6204U (KOYO)

Price €22.60
#33 91318-ME5-003

O-RING, 56X19 (ARAI)

Price €6.30
#34 95701-0601600

BOLT, FLANGE, 6X16

Price €1.15
