LEFT CRANKCASE COVER 🏍️ Shadow
STARTING MOTOR 🏍️ Shadow

WATER PUMP for Shadow REARL SEDONA RED (R223) from 1999

WATER PUMP for Shadow REARL SEDONA RED (R223) from 1999
Reference
Product name
#1 11364-MAH-000

COVER, STARTER

Price €77.94
#2 11365-MM8-881

GASKET, STARTER COVER

Price €8.24
#3 19200-MAA-A00

PUMP ASSY, WATER

Price €444.98
#4 19221-MAH-000

COVER COMP, WATER PUMP

Price €116.45
#5 19226-ME9-000

GASKET, WATER PUMP COVER

Price €6.76
#6 28130-MAH-000

SHAFT COMP, STARTER DRIVE (36T)

Price €129.46
Contact us
#7 28140-MG8-000

LIMITER ASSY, TORQUE

Price €446.77
#8 90004-GHB-690

BOLT, FLANGE, 6X32 (NSHF)

Price €3.83
#9 90004-GHB-710

BOLT, FLANGE, 6X40 (NSHF)

Price €3.82
#10 90004-GHB-720

BOLT, FLANGE, 6X45 (NSHF)

Price €6.60
#11 90004-GHB-780

BOLT, FLANGE, 6X75 (NSHF)

Price €7.27
#12 90045-ZG1-770

BOLT, STUD, 6X25

Price €3.44
#13 90121-MV9-670

BOLT, FLANGE, 6X25

Price €1.96
#14 90463-ML7-000

WASHER, SEALING, 65MM

Price €5.84
#15 91002-MG8-003

BEARING, RADIAL BALL, 6804 (KOYO)

Price €37.79
#16 91201-MG8-000

CAP, RUBBER

Price €7.36
#17 91302-MB0-013

O-RING, 3295X262 (ARAI)

Price €5.39
#18 91410-679-000

CLIP, 2X60

Price €8.47
#19 94301-08140

DOWEL PIN, 8X14

Price €2.02
#20 95701-0604500

BOLT, FLANGE, 6X45

Price €1.62
#21 96100-6000000

BEARING, RADIAL BALL, 6000

Price €12.44
