METER for Shadow PEARL HERON BLUE (PB332X) from 2011

METER for Shadow PEARL HERON BLUE (PB332X) from 2011
Reference
Product name
#1 17368-KV7-671

PIPE CLIP

Price €6.52
#2 18422-MCS-760

RUBBER, EX PIPE MOUNTING

Price €37.62
#3 32103-MGR-671 i

SUB HARNESS, METER

Price €184.91
#4 37205-MGR-003 i

SWITCH ASSY, RESET

Price €38.12
#5 37210-MGR-641 i

SPEEDOMETER COMP (KPH)

Price €1,695.23
#6 37211-MGR-670

STAY, METER

Price €100.76
#7 37212-MGR-000

WASHER, PLAIN, 6MM

Price €6.54
#8 37215-MBA-611 i

CAP, RESET SWITCH

Price €13.69
#9 37220-MGR-671 i

COVER A, SPEEDOMETER

Price €47.59
#10 37230-MGR-671 i

COVER B, SPEEDOMETER

Price €34.07
#11 37235-MCL-000

CUSHION, RUBBER

Price €27.35
#12 37700-MGR-671

SENSOR ASSY, SPEED

Price €330.82
#13 90101-MFY-A00

BOLT, FLANGE, 8X16

Price €5.00
#14 90102-HN1-A70

SCREW-WASHER, 5X20

Price €7.22
#15 90133-SL9-003

SCREW-WASHER, 3X18

Price €5.16
#16 90690-GHB-631 i

WIRE CLIP, 8MM

Price €2.08
#17 91301-027-000

O-RING, 6.8X1.9

Price €5.58
#18 93913-24480

SELF-TAPPING SCREW, 4X16 (PO)

Price €0.64
#19 94001-060700S i

NUT HEX., 6MM

Price €0.88
