CYLINDER HEAD (FRONT) (VT1100CV/CW/C2) 🏍️ Shadow
CAMSHAFT/VALVE 🏍️ Shadow

CYLINDER HEAD (REAR) (VT1100CV/CW/C2) for Shadow PEARL CANYON COPPER (YR188U) from 1998

CYLINDER HEAD (REAR) (VT1100CV/CW/C2) for Shadow PEARL CANYON COPPER (YR188U) from 1998
Reference
Product name
#1 12220-MAH-000

HEAD COMP, RR CYLINDER

Contact us
#2 12222-MAH-000

FIN A, RR CYLINDER HEAD

Contact us
#3 12223-MAH-000

FIN B, RR CYLINDER HEAD

Contact us
#4 12225-MG8-000

SLEEVE, PLUG

Price €51.73
#5 12231-MG8-305

GUIDE, IN VALVE (OS)

Price €41.51
#6 12233-MG8-305

GUIDE, EX VALVE (OS)

Price €52.16
#7 12251-MAH-003

GASKET, CYLINDER HEAD

Price €49.32
#8 12312-ME9-750

PLUG, CAMSHAFT

Price €13.07
#9 16211-MAH-000

INSULATOR, CARBURETOR

Price €43.27
#10 16218-MAH-000

BAND A, INSULATOR

Price €17.54
#11 16219-MAH-000

BAND B, INSULATOR

Price €19.54
#12 16222-MV4-300

NUT, SQUARE, 5MM

Price €3.23
#13 32905-MAH-000

CLIP, HIGH TENSION CORD

Contact us
#14 64528-KV3-000

NUT, WELL, 5MM

Price €6.98
#15 90035-MAH-000

BOLT, STUD, 8X31

Price €7.10
#16 90452-323-000

WASHER, SEALING, 5MM

Price €2.42
#17 91304-MG7-003

O-RING, 274X24 (ARAI)

Price €7.60
#18 91351-MG7-004

O-RING, 353X24 (NOK)

Price €8.35
#19 93500-050080A

SCREW, PAN, 5X8

Price €0.92
#20 93500-050120G

SCREW, PAN, 5X12

Price €0.77
#21 93500-050250G

SCREW, PAN, 5X25

Price €0.84
#22 95701-0603507

BOLT, FLANGE, 6X35

Price €1.39
#23 96700-0602007

BOLT, SOCKET, 6X20

Price €1.15
#24 96700-0603507

BOLT, SOCKET, 6X35

Price €1.33
#25 96700-0604507

BOLT, SOCKET, 6X45

Price €2.33
Contact us
#26 98069-56916

PLUG, SPARK (DPR6EA-9) (NGK)

Price €11.15
#26 98069-56926

PLUG, SPARK (X20EPR-U9) (DENSO)

Price €11.15
#26 98069-57916

PLUG, SPARK (DPR7EA-9) (NGK)

Price €6.41
#26 98069-57926

PLUG, SPARK (X22EPR-U9)

Price €6.41
#26 98069-58916

PLUG, SPARK (DPR8EA-9) (NGK)

Price €6.41
#26 98069-58926

PLUG, SPARK (X24EPR-U9) (DENSO)

Price €6.41
