FRONT FORK for SH300A PEARL SPLENDOR RED (R369) from 2019

FRONT FORK for SH300A PEARL SPLENDOR RED (R369) from 2019
Reference
Product name
#1 33741-KTG-U01 i

REFLECTOR, FR REFLEX (AMBER)

Price €26.70
#2 51400-KTW-B01

FORK ASSY, R FR

Price €644.92
#3 51401-KTW-B01

SPRING, FR FORK

Price €18.66
#4 51410-KTW-B01

PIPE COMP, FR FORK

Price €101.83
#5 51412-422-003 i

RING, BACK UP

Price €14.33
#6 51414-MBV-711 i

BUSH, GUIDE

Price €26.24
#7 51415-MBV-711 i

BUSH, SLIDER

Price €15.61
#8 51416-461-003

SPRING, REBOUND

Price €13.60
#9 51420-KTW-B01

CASE, R FR BOTTOM

Price €181.45
#10 51432-KTW-902 i

PIECE, OIL LOCK

Price €25.86
#11 51437-461-003

RING, PISTON

Price €17.66
#12 51440-KTW-901

PIPE, SEAT

Price €67.36
#13 51447-KTW-902 i

RING, OIL SEAL STOPPER

Price €14.57
#14 51449-KTW-901

CAP, FR FORK TOP

Price €12.60
#15 51455-KTW-902 i

SEAT B, SPRING

Price €16.79
#16 51456-KTW-901

RING, STOPPER

Price €3.97
#17 51490-KTW-B01

SEAL SET, FR FORK

Price €37.13
#18 51500-KTW-B01

FORK ASSY, L FR

Price €644.92
#19 51520-KTW-B01

CASE, L FR BOTTOM

Price €181.45
#20 61104-K53-D00

STAY, FR REFLECTOR

Price €7.44
#21 90109-K53-D00

SCREW, SPECIAL, 5MM

Price €7.08
#22 90109-MR7-000 i

BOLT, FLANGE, 8X45

Price €6.94
#23 90116-KTW-901

BOLT, SOCKET, 8X20

Price €4.96
#24 90301-KGH-901

NUT, U, 6MM (FUJI SEIMITSU)

Price €3.16
#25 90302-KVB-T01

NUT, U, 5MM

Price €1.44
#26 90544-283-000 i

WASHER, SPECIAL, 8MM (SHOWA)

Price €6.26
#27 91254-KTW-901

SEAL, DUST

Price €18.37
#28 91356-KTW-901

O-RING, 262X24

Price €3.97
#29 61105-K53-D00

STAY, L FR REFLECTOR

Price €7.44
