PANEL/STAND for Pan-European CANDY GLORY RED-U (R101CU) from 1992

PANEL/STAND for Pan-European CANDY GLORY RED-U (R101CU) from 1992
Reference
Product name
#1 24700-MY3-000

PEDAL ASSY, GEAR CHANGE

Contact us
#2 24705-MK3-000

COLLAR, GEAR CHANGE PEDAL PIVOT

Price €16.91
#3 24706-MK3-770

RUBBER, DUST SEAL

Price €8.72
#4 24710-MY3-000

ARM COMP, GEAR CHANGE

Price €71.35
Contact us
#5 24720-MT3-000

PEDAL COMP, GEAR CHANGE

Price €106.88
Contact us
#6 24724-422-000

COVER, DUST

Price €16.20
#7 24781-KR3-770

RUBBER, GEAR CHANGE PEDAL

Price €8.78
#8 35350-MT3-000 i

SWITCH ASSY, RR STOP

Price €28.48
Contact us
#9 35357-MT3-000

SPRING, STOP SWITCH

Price €10.03
Contact us
#10 35700-MT3-305

SWITCH SET, SIDE STAND

Price €105.94
#11 46500-MT3-000

PEDAL COMP, RR BRAKE

Contact us
#12 46515-MT3-000

SPRING ASSY, BRAKE RETURN

Price €9.11
Contact us
#13 50500-MT3-010 i

STAND COMP, MAIN

Price €372.13
#14 50520-MT3-601 i

SPRING ASSY, MAIN STAND

Price €23.95
#17 50523-MT4-000

RUBBER, MAIN STAND SPRING

Price €8.41
#18 50524-MT3-601 i

TUBE, MAIN STAND SPRING

Price €12.56
#19 50526-MT3-000

PIPE, MAIN STAND PIVOT

Price €36.07
#20 50530-MY3-000 i

BAR, SIDE STAND

Price €153.25
#21 50540-MT3-611

SPRING ASSY, SIDE STAND

Price €117.50
Contact us
#24 50543-MT3-611 i

TUBE, SIDE STAND SPRING

Price €5.93
#25 50713-KC1-700

PLATE, PILLION STEP SIDE

Price €10.99
#26 53312-657-000

WASHER, BUSH

Price €9.00
#27 64515-MT3-000

GUIDE, BREATHER

Price €17.58
Contact us
#28 90028-PL1-000

BOLT, SPECIAL, 6X25

Price €3.49
Contact us
#29 90065-MT3-000

BOLT, TIE ROD

Price €4.86
Contact us
#30 90108-MR5-000

BOLT, SIDE STAND PIVOT

Price €12.30
#31 90147-MK6-671 i

BOLT, SPECIAL, 6X16

Price €7.19
#32 90201-700-000 i

NUT, GOVERNOR ARM FIXING (LEFT HAND THREAD)

Price €0.86
#33 90203-MF9-710 i

NUT, SIDE STAND

Price €7.32
#34 90309-428-731 i

NUT, FLANGE (SELF-LOCK) (M8X125)

Price €10.28
#35 90514-921-000

WASHER, 8MM

Price €1.86
#36 91251-MT4-000 i

DUST SEAL, 15X20X3

Price €4.82
#37 94002-060200S i

NUT, HEX, 6MM

Price €1.00
#38 94050-08070 i

NUT, FLANGE, 8MM

Price €1.08
#39 94201-25250

PIN, SPLIT, 25X25

Price €0.88
#40 94511-15000

CIRCLIP, EXTERNAL, 15MM

Price €0.94
#41 95801-0804507

BOLT, FLANGE, 8X45

Price €1.74
#42 95701-0804507 i

BOLT, FLANGE, 8X45

Price €1.50
