CRANKCASE (CB400XA/CB500XA) for NX500 GRAPHITE BLACK (NHB01) from 2026

CRANKCASE (CB400XA/CB500XA) for NX500 GRAPHITE BLACK (NHB01) from 2026
Reference
Product name
#20 90463-ML7-000 i

WASHER SEALING, 6.5MM

Price €4.62
#30 95701-0603500 i

FLANGE BOLT, 6X35

Price €1.34
#1 11000-MLR-DL0

SET OF CASE ENGINE

Contact us
#2 11103-MGZ-J00

PIN, PARTITION

Price €5.80
#3 11140-MGZ-J00

COMP. JET, OIL

Price €23.60
#4 11150-MLH-A00

CAP, CASE ENGINE

Price €16.14
#5 12207-KYJ-900

BOLT SEALING, 12MM

Price €3.25
#6 15515-MGZ-J00

ELEMENT PUMP A OIL

Price €3.16
#7 19060-MGZ-J00

GASKET WATER

Price €22.48
#8 32101-MLR-D00

ENGINE AUXILIARY ELECTRIC HARNESS

Price €29.93
#9 32102-MKP-DQ0

HARNESS SECONDARY, PRESSURE OIL

Price €15.62
#10 32157-MGZ-J00

WIRE HARNESS CLIP SUPPORT

Price €5.00
#11 35500-MEH-661

ASSY. SWITCH OF PRESSURE OIL (DENSO)

Price €82.79
#12 35759-MKP-T02

ASSY. SWITCH OF CHANGE

Price €110.63
#13 90002-PA6-003

WASHER A BOLT, 4X8 (DENSO)

Price €6.14
#14 90005-MAZ-000

BOLT OF SOCKET, 10MM

Price €5.71
#15 90009-MGZ-J00

BOLT OF SOCKET, 10MM

Price €9.90
#16 90011-MGP-000

BOLT, HEAD CREUSE A COGNER 6MM

Price €17.89
#17 90015-MGZ-J01

BOLT UBS, 8X105

Price €15.95
#18 90048-MY5-600

BOLT SEALING, 18MM

Price €17.57
#19 90442-028-000

WASHER SEALING, 8MM

Price €5.71
#21 90701-MV9-670

STUD, 10X16

Price €7.63
#22 91303-KF0-003 i

O-RING, 14.8X2.4 (ARAI)

Price €4.70
#23 91304-MCP-900

O-RING, 23X24

Price €7.57
#24 91305-KC1-850

O-RING, 16.5X2.5

Price €6.06
#25 91305-MCJ-751 i

O-RING, 3.2X1.1

Price €4.98
#26 92900-060160E

STUD, 6X16

Price €1.98
#27 94050-06000 i

FLANGE NUT, 6MM

Price €0.79
#28 95701-0601200 i

FLANGE BOLT, 6X12

Price €1.15
#29 95701-0601800 i

FLANGE BOLT, 6X18

Price €1.15
#31 95701-0604008 i

FLANGE BOLT, 6X40

Price €1.34
#32 95701-0609500

FLANGE BOLT, 6X95

Price €3.06
#33 95701-0805500 i

FLANGE BOLT, 8X55

Price €2.87
#34 95701-0807500

FLANGE BOLT, 8X75

Price €3.06
#35 95701-1007500 i

FLANGE BOLT, 10X75

Price €3.73
#36 96001-0601407 i

FLANGE BOLT, 6X14

Price €1.34
