TRANSMISSION (MAINSHAFT) for NX500 GRAND PRIX RED (R380) from 2025

TRANSMISSION (MAINSHAFT) for NX500 GRAND PRIX RED (R380) from 2025
Reference
Product name
#1 23211-MKP-D00

SHAFT MAIN (14T)

Price €99.60
#2 23212-MGZ-J00

BEARING FIXING PLATE

Price €23.99
#3 23431-MKP-D00

PINION DEUXIEME SHAFT MAIN (19T)

Price €46.36
#4 23451-MKP-D00

PINION TROISIEME ET QUATRIEME SHAFT OF RENVOI...

Price €102.13
#5 23491-MKP-D00

PINION CINQUIEME SHAFT MAIN (20T)

Price €63.00
#6 23492-MGZ-J00

BAND, 25X28X12

Price €23.64
#7 23511-MKP-D00

PINION SIXIEME SHAFT MAIN (23T)

Price €62.64
#8 23512-MV9-670

BAND CANNELEE, 25X28X13

Price €32.23
#9 23531-MGZ-J00

BEARING FIXING PLATE

Price €9.55
#10 90005-MGZ-J00

FLANGE BOLT, 6X14 (NSHF)

Price €2.98
#11 90403-KE7-000

WASHER OF STOPPER, 17.2MM

Price €7.20
#12 90451-KY2-000

WASHER CANNELEE, 25X31X1.5

Price €7.48
#19 95701-0601400 i

FLANGE BOLT, 6X14

Price €1.15
#13 90454-KYJ-900

WASHER CANNELEE, 25X42X1.6

Price €8.92
#14 90455-KYJ-900

WASHER BLOCAGE, 25MM

Price €56.69
#15 90456-MA6-000

WASHER OF STOPPER, 25MM

Price €7.61
#16 90601-107-000

CIRCLIP, 25MM

Price €7.91
#17 91022-MN4-003

NEEDLE BEARING, 17X27X14.8 (TOYO)

Price €26.09
#18 91023-MN4-003 i

OUTER OF NEEDLE BEARING

Price €34.56
#20 96100-6305000 i

RADIAL BALL BEARING, 6305

Price €28.32
