TRANSMISSION for NSS125AD MAT CYNOS GRAY METALLIC (NH312) from 2015

TRANSMISSION for NSS125AD MAT CYNOS GRAY METALLIC (NH312) from 2015
Reference
Product name
#1 11211-K40-F00

TUBE, MISSION BREATHER

Price €12.10
#2 21200-K40-F00

CASE COMP, MISSION

Price €121.26
#3 21395-KZR-600

GASKET, TRANSMISSION CASE

Price €15.53
#4 23411-K40-F00

DRIVESHAFT (17T)

Price €193.14
#5 23421-K40-F00

COUNTERSHAFT (13T)

Price €87.64
#6 23422-K40-F00

GEAR, COUNTER (53T)

Price €100.92
#7 23430-K40-F00

GEAR COMP, FINAL (44T)

Price €336.04
#8 90495-MN5-000

WASHER, SEALING, 8MM

Price €5.50
#9 91005-KZR-601

BEARING, RADIAL BALL, 6301 (NTN)

Price €29.18
#10 91006-KAB-004

BEARING, RADIAL BALL, 6205-2NSG (FUJIKOSHI)

Price €32.11
#11 91006-KZR-601

BEARING, RADIAL BALL, 6201 (NTN)

Price €29.18
#12 91204-K35-J01

OIL SEAL, 34X52X7 (ARAI)

Price €12.08
#13 94301-10120

DOWEL PIN, 10X12

Price €2.04
#14 95002-50000

CLIP, TUBE (C9)

Price €0.77
#15 95701-0804500

BOLT, FLANGE, 8X45

Price €1.70
#16 95701-0805500

BOLT, FLANGE, 8X55

Price €2.81
# 22100-KFG-000

OUTER COMP, CLUTCH

Price €174.18
# 22350-K40-F01

PLATE COMP, DRIVE

Price €65.52
# 22361-KFG-000

PLATE, CLUTCH SIDE

Price €21.02
# 22401-KFF-900

SPRING, CLUTCH

Price €4.50
# 22535-K40-F00

WEIGHT SET, CLUTCH

Price €113.28
# 22804-GB2-000

RUBBER, CLUTCH DAMPER

Price €5.36
# 23100-K40-F01

BELT, DRIVE

Price €45.90
# 23205-K40-F00

FACE SET, DRIVEN

Price €663.24
# 23224-K40-F00

FACE SET, MOVABLE DRIVEN

Price €357.17
# 23225-KSY-900

PIN, ROLLER GUIDE

Price €4.50
# 23226-KVB-900

ROLLER, GUIDE

Price €4.13
# 23233-KZY-902

SPRING, DRIVEN FACE

Price €27.90
# 23237-K40-F00

COLLAR, SEAL

Price €29.76
# 23238-KWN-900

COLLAR, SPRING

Price €12.01
# 90202-KN7-670

NUT, SPECIAL, 28MM

Price €8.34
# 90441-GY6-940

WASHER, 122X29X25

Price €8.62
# 90603-KSV-J10

CIRCLIP, INTERNAL, 28MM

Price €6.48
# 90605-166-720

CIRCLIP, 7MM

Price €4.19
# 91002-GA7-701

BEARING, RADIAL BALL, 6902U (NTN)

Price €21.01
# 91009-KVY-961

BEARING, RADIAL BALL, 6902U (NSK)

Price €27.31
# 91002-KFG-003

BEARING, NEEDLE, 22X29X18

Price €30.88
# 91211-K44-V01

SEAL, DRIVEN FACE, 34X41X4

Price €4.20
# 91384-KVB-900

O-RING, 388X19

Price €4.60
# 94030-12200

NUT, HEX, 12MM

Price €1.39
