TRANSMISSION for NSC110 CANDY NOBLE RED (R350) from 2021

TRANSMISSION for NSC110 CANDY NOBLE RED (R350) from 2021
Reference
Product name
#1 11204-KGF-900

SLEEVE, RR BRAKE CAM

Price €24.01
#10 91006-KZR-601

BEARING, RADIAL BALL, 6201 (NTN)

Price €7.55
#12 91201-434-003 i

OIL SEAL, 14X20X32 (ARAI)

Price €6.83
#14 91304-K0L-D01

O-RING, 114X21

Price €3.46
#15 94301-08100 i

DOWEL PIN, 8X10

Price €1.81
#16 94510-20000 i

CIRCLIP, EXTERNAL, 20MM

Price €1.08
#17 95002-50000 i

CLIP, TUBE (C9)

Price €0.78
#18 95701-0602800 i

BOLT, FLANGE, 6X28

Price €1.25
#19 95701-0603800

BOLT, FLANGE, 6X38

Price €1.18
#20 96001-0601600 i

BOLT, FLANGE, 6X16

Price €1.25
#2 21200-K2C-V00

CASE COMP, TRANSMISSION

Price €81.88
#3 21211-K2C-V00

TUBE, TRANSMISSION BREATHER

Price €4.74
#4 21395-K1A-N02 i

GASKET, MISSION CASE (NIPPON LEAKLESS)

Price €5.82
#5 23411-K0J-N00

DRIVESHAFT (18T)

Price €35.72
#6 23421-K0J-N00

COUNTERSHAFT (12T)

Price €23.08
#7 23422-K0J-N00

GEAR, COUNTER (51T)

Price €23.39
#8 23430-K0J-N00

GEAR COMP, FINAL (45T)

Price €63.79
#9 37700-K0L-D11

SENSOR ASSY, SPEED (PANASONIC)

Price €19.06
#11 91009-K50-T01

BEARING, RADIAL BALL, 60/22 UU (FUJIKOSHI)

Price €22.07
#13 91204-K44-V01

OIL SEAL, 29X44X7 (ARAI)

Price €1.44
