PEDAL for NC750XA CANDY CHROMOSPHERE RED (R381) from 2018

PEDAL for NC750XA CANDY CHROMOSPHERE RED (R381) from 2018
Reference
Product name
#1 24705-MGS-D30 i

PEDAL COMP, CHANGE

Price €107.44
#2 24706-MK3-770

RUBBER, DUST SEAL

Price €8.72
#3 24710-MGS-D30

ARM COMP, CHANGE

Price €161.38
#4 24724-MBW-D21

COVER, DUST

Price €16.73
#5 24781-KR3-770

RUBBER, GEAR CHANGE PEDAL

Price €8.78
#6 35350-MGS-D32 i

SWITCH ASSY, RR STOP

Price €72.06
#7 35357-MGS-D30

SPRING, STOP SWITCH

Price €12.42
#8 46500-MGS-D30 i

PEDAL COMP, BRAKE

Price €107.56
#9 46511-MV9-000 i

SPRING, BRAKE PEDAL

Price €3.73
#10 50715-KE8-000

PLATE, PILLION STEP SIDE

Price €10.69
#11 90010-ML0-720

BOLT, FLANGE, 6X20

Price €5.21
#12 90115-KAF-000

BOLT, CHANGE PIVOT

Price €22.55
#13 90165-MGS-D30

BOLT A, TIE ROD

Price €15.73
#14 90201-KV3-700

NUT B, TIE ROD (LEFT HAND THREAD)

Price €5.16
#15 90514-921-000

WASHER, 8MM

Price €1.86
#16 90601-KAF-003

CLIP, SWITCH COVER

Price €6.23
#17 94002-060200S i

NUT, HEX, 6MM

Price €1.00
#18 94511-19000

CIRCLIP, EXTERNAL, 19MM

Price €1.31
