THROTTLE BODY for MSX125A LEMON ICE YELLOW (Y196) from 2017

THROTTLE BODY for MSX125A LEMON ICE YELLOW (Y196) from 2017
Reference
Product name
#1 16016-K03-H11

SET DE SCREW

Price €6.12
#2 16075-KYZ-711

O-RING

Price €7.39
#3 16077-KVB-S51

GASKET TORIQUE, 1.9X20.4

Price €5.46
#4 16081-KYJ-901

BOLT, TORX 5X87

Price €6.37
#5 16169-K26-901

STAY, WIRE

Price €27.79
#8 16450-K03-H11

INJECTOR ASSY, FUEL

Price €81.50
#9 16472-KPC-D50

RING OF GASKET

Price €6.80
#10 16480-KVB-S51

SOLENOIDE

Price €73.50
#11 16485-GGZ-J01

SEAT SET

Price €13.81
#12 17560-K26-900

JOINT COMP, INJECTOR

Price €50.76
#14 90001-K26-900

BOLT, FLANGE, 6X22

Price €10.70
#15 91301-GGL-J01

O-RING, 6.3X2.2

Price €21.91
#16 93892-0501218 i

SCREW A HEAD A WASHER, 5X12

Price €1.34
#17 96001-0602000 i

FLANGE BOLT, 6X20

Price €1.25
#6 16400-K26-B11

BODY ASSY, THROTTLE (GQY4B A)

Price €99.07
#7 16410-K26-B11

BODY SET

Price €68.03
#13 17570-K26-C11

HOSE COMP, FUEL FEED

Price €34.12
