CRANKCASE (CB500FAC) for Hornet 500 GRAND PRIX RED (R380) from 2026

CRANKCASE (CB500FAC) for Hornet 500 GRAND PRIX RED (R380) from 2026
Reference
Product name
#22 90463-ML7-000 i

WASHER SEALING, 6.5MM

Price €4.62
#34 95701-0603500 i

FLANGE BOLT, 6X35

Price €1.34
#2 11103-MGZ-J00

PIN, PARTITION

Price €5.80
#3 11140-MGZ-J00

COMP. JET, OIL

Price €23.60
#4 12207-KYJ-900

BOLT SEALING, 12MM

Price €3.25
#5 15515-MGZ-J00

ELEMENT PUMP A OIL

Price €3.16
#6 19060-MGZ-J00

GASKET WATER

Price €22.48
#8 32102-MJW-J00

HARNESS SECONDAIRE, PRESSURE OIL

Price €17.26
#9 32157-MGZ-J00

WIRE HARNESS CLIP SUPPORT

Price €5.00
#10 35500-MEH-661

ASSY. SWITCH OF PRESSURE OIL (DENSO)

Price €82.79
#11 35600-MKF-D41

ASSY. SWITCH NEUTRAL

Price €50.26
#12 37700-MJE-D01

ASSY. SENDER OF SPEED (TDK-EPC)

Price €47.42
#14 90002-PA6-003

WASHER A BOLT, 4X8 (DENSO)

Price €6.14
#15 90005-MAZ-000

BOLT OF SOCKET, 10MM

Price €5.71
#16 90009-MGZ-J00

BOLT OF SOCKET, 10MM

Price €9.90
#17 90011-MGE-D00

BOLT OF STUD, 6MM

Price €8.03
#18 90015-MGZ-J01

BOLT UBS, 8X105

Price €15.95
#19 90048-MY5-600

BOLT SEALING, 18MM

Price €17.57
#20 90442-028-000

WASHER SEALING, 8MM

Price €5.71
#21 90443-MJ6-000

WASHER OF NEUTRAL

Price €5.02
#23 90650-KW3-000

WIRE BAND

Price €9.46
#24 90701-MV9-670

STUD, 10X16

Price €7.63
#25 91303-KF0-003 i

O-RING, 14.8X2.4 (ARAI)

Price €4.70
#26 91304-MCP-900

O-RING, 23X24

Price €7.57
#27 91305-MCJ-751 i

O-RING, 3.2X1.1

Price €4.98
#28 91310-MGE-D01

O-RING, 16.5X2.5

Price €14.00
#29 92900-060160E

STUD, 6X16

Price €1.98
#30 94050-04080

FLANGE NUT, 4MM

Price €0.88
#31 94050-06000 i

FLANGE NUT, 6MM

Price €0.79
#32 95701-0601200 i

FLANGE BOLT, 6X12

Price €1.15
#33 95701-0601800 i

FLANGE BOLT, 6X18

Price €1.15
#35 95701-0604008 i

FLANGE BOLT, 6X40

Price €1.34
#36 95701-0609500

FLANGE BOLT, 6X95

Price €3.06
#37 95701-0805500 i

FLANGE BOLT, 8X55

Price €2.87
#38 95701-0807500

FLANGE BOLT, 8X75

Price €3.06
#39 95701-1007500 i

FLANGE BOLT, 10X75

Price €3.73
#40 96001-0601407 i

FLANGE BOLT, 6X14

Price €1.34
#1 11000-MLR-DN0

SET OF CASE ENGINE

Contact us
#7 32101-MLR-DN0

HARNESS AUXILIARY ENGINE

Contact us
#13 38800-MLR-DN1

ASSEMBLAGE OF SENSEUR D'ANGLE (350DEG)

Contact us
