HANDLE LEVER/SWITCH/ CABLE 🏍️ Dominator 250
HANDLE PIPE/TOP BRIDGE 🏍️ Dominator 250

FR. BRAKE MASTER CYLINDER for Dominator 250 FIGHTING RED (R134) from 1988

FR. BRAKE MASTER CYLINDER for Dominator 250 FIGHTING RED (R134) from 1988
Reference
Product name
#1 35340-MA5-671

SWITCH ASSY, FR STOP

Price €36.31
#1 35340-MM5-600

SWITCH ASSY, FR STOP

Price €44.35
#2 45125-KW3-003

HOSE, FR BRAKE UPPER

Contact us
#3 45126-KW3-003

HOSE, FR BRAKE LOWER

Contact us
#4 45127-KA3-831

JOINT, BRAKE HOSE

Price €26.96
Contact us
#5 45135-KW3-000

PIPE COMP, FR BRAKE

Contact us
#6 45463-KW3-000

STAY, FR BRAKE HOSE

Contact us
#7 45464-KW3-000

CLAMPER, FR BRAKE PIPE

Contact us
#8 45500-KW3-671

CYLINDER ASSY, FR BRAKE MASTER (NISSIN)

Contact us
#9 45504-410-003

BOOT COMP

Price €15.22
#10 45506-KA3-731

SPRING

Price €9.42
#12 45513-KK1-771

CAP, MASTER CYLINDER

Price €54.41
#13 45517-166-006

HOLDER, MASTER CYLINDER

Price €22.57
#14 45518-MG3-016

SEPARATOR COMP

Price €19.55
#16 45520-MG7-006

DIAPHRAGM

Price €24.06
#16 45521-HA2-006

PLATE, DIAPHRAGM

Price €13.94
#17 45530-MN9-305

CYLINDER SET, MASTER

Price €69.78
#18 53175-KM9-006

LEVER COMP, R HANDLE

Price €18.78
#19 90114-MA5-671

BOLT, HANDLE LEVER PIVOT

Price €11.93
#20 90145-KM3-750

BOLT, OIL, 10X22

Price €13.75
#21 90201-415-000

NUT, CAP, 6MM

Price €5.94
#22 90545-300-000

WASHER, OIL BOLT

Price €6.41
#23 90651-MA5-671

CIRCLIP

Price €5.83
#24 93600-040121G

SCREW, FLAT, 4X12

Price €0.76
#25 93893-0401218

SCREW-WASHER, 4X12

Price €0.97
#26 96001-0601000

BOLT, FLANGE, 6X10

Price €1.39
#27 96001-0601200

BOLT, FLANGE, 6X12

Price €1.22
#28 96001-0602007

BOLT, FLANGE, 6X20

Price €1.39
#28 96001-0602207

BOLT, FLANGE, 6X22

Price €1.70
