SWINGARM for CRF450R EXTREME RED (R292) from 2022

SWINGARM for CRF450R EXTREME RED (R292) from 2022
Reference
Product name
#2 40531-MKE-AF1

JOINT, DRIVE CHAIN

Price €28.06
#4 40540-MKE-AF1

CHAIN, DRIVE (DAIDO) (DID520DM2-120RB)...

Price €251.44
#5 43468-KRN-C90

GUIDE A, BRAKE HOSE

Price €7.97
#6 52101-KZ4-J40

SHAFT, SWINGARM PIVOT

Price €46.61
#7 52141-MKE-A70

COLLAR, SWINGARM (47MM)

Price €30.12
#8 52143-MEN-A30

WASHER, SWINGARM SIDE THRUST

Price €7.66
#9 52143-MKE-A60

COLLAR, SWINGARM PIVOT SIDE

Price €14.84
#10 52146-MKE-A01

GUIDE SET, CHAIN

Price €51.53
#11 52147-MEN-J00

PLATE, CHAIN GUIDE

Price €84.20
#12 52160-MEN-000

COLLAR, CHAIN TENSIONER

Price €7.85
#13 52170-MKE-AF0

SLIDER, CHAIN

Price €88.44
#14 52171-KR6-000

WASHER, CHAIN SLIDER

Price €2.09
#15 52175-MKE-A00

ROLLER COMP, CHAIN (34MM)

Price €67.99
#16 52176-MKE-A00

ROLLER COMP, CHAIN LOWER (34MM)

Price €67.99
#17 52200-MKE-AF0

SWINGARM SUB ASSY, RR

Price €1,869.47
#18 90020-GHB-620

BOLT, FLANGE, 6X12

Price €5.03
#19 90020-GHB-750

BOLT, FLANGE, 6X45

Price €7.21
#20 90101-MEN-A70

BOLT, FLANGE, 8X32

Price €8.70
#21 90101-MKE-A70

SCREW, PAN, 5X8

Price €4.14
#22 90105-MEN-000

BOLT, HEX, 8X475

Price €7.58
#23 90301-473-003

NUT, U, 6MM (FUSE RASHI)

Price €7.24
#24 90305-KZ3-B01

NUT, U, HEX 14MM

Price €7.88
#25 90309-357-000

NUT, HEX, 8MM

Price €10.68
#26 90501-GBL-730

WASHER, 14MM

Price €7.39
#27 91051-KRN-A31

BEARING, RADIAL BALL, 608UU

Price €39.25
#28 91071-MJ0-003

BEARING, NEEDLE, 22X29X30 (NTN)

Price €38.08
#29 91072-KZ3-861

BEARING, NEEDLE THRUST

Price €21.16
#30 91251-MKE-A01

DUST SEAL, 30X37X3

Price €10.38
#31 91252-MKE-A01

DUST SEAL, 22X29X3

Price €10.01
#32 93500-050080G

SCREW, PAN, 5X8

Price €0.84
#33 94103-05700

WASHER, PLAIN, 5MM

Price €0.77
