THROTTLE BODY for CRF450R EXTREME RED (R292) from 2011

THROTTLE BODY for CRF450R EXTREME RED (R292) from 2011
Reference
Product name
#1 16046-MEN-A41

VALVE COMP, STARTER

Price €57.74
#2 16080-HP1-601

BOLT, COVER

Price €10.52
#3 16157-MEN-A31

COVER, BODY

Price €50.56
#4 16191-MEN-A31

STAY, PB SENSOR

Price €30.49
#7 16422-MEN-A31

JOINT, INJECTOR

Price €29.17
#9 16472-MCW-000

SEAL RING, INJECTOR

Price €7.04
#10 16473-P7A-004

CUSHION RING, INJECTOR

Price €7.64
#11 17567-MEN-A31

BASE, CLAMP

Price €12.62
#12 17568-HP5-600

CLAMPER, FUEL HOSE

Price €5.08
#13 17579-HP5-600

RUBBER, FUEL FEED HOSE

Price €4.58
#14 37830-MEL-003

SENSOR ASSY, MAP

Price €375.91
#15 90002-892-000

BOLT, FLANGE, 5X10

Price €1.69
#16 91301-P7A-004

O-RING, 78X19

Price €5.71
#17 93401-0502000

BOLT-WASHER, 5X20

Price €1.18
#18 93892-0501218

SCREW-WASHER, 5X12

Price €1.32
#19 16542-MEN-A41

SCREW-WASHER, 6X25

Price €9.94
#5 16199-MEN-A51

TUBE

Price €23.12
#6 16400-MEN-A51

THROTTLE BODY ASSY (GQ25A A)

Price €1,379.89
Contact us
#8 16450-MEN-A51

INJECTOR ASSY, FUEL

Price €300.26
