WIRE HARNESS (CRF250LR/LRA,CRF300LR/LRA) for CRF300LRA EXTREME RED (R292) from 2021

WIRE HARNESS (CRF250LR/LRA,CRF300LR/LRA) for CRF300LRA EXTREME RED (R292) from 2021
Reference
Product name
#1 30510-K1T-E11

COIL COMP, IGNITION

Price €29.34
#2 30520-GFM-900

SPACER OF COIL D'IGNITION

Price €9.52
#3 30700-KZZ-901

CAP ASSY, NOISE SUPPRESSOR

Price €47.51
#4 31600-KZZ-J01

RECTIFIER ASSY, REGULATE

Price €211.56
#6 31730-MAS-601 i

DIODENEINHEIT, DREIWEG (SUMITOMO)

Price €22.76
#9 32146-S84-003

CONNECTION, DIODE (2P) (3A)

Price €24.08
#10 32161-404-000 i

STRIPE B1 OF CABLE

Price €9.78
#12 35160-KVS-751

ASSY. SENSEUR, ANGLE D'INCLINAISON (M6)

Price €228.97
#13 35161-K1T-E10

RUBBER, HEAT GUARD

Price €13.52
#14 35161-KZZ-900

STAY, BANK ANGLE SENSOR

Price €6.13
#15 37244-MM4-000

RUBBER OF MOUNTING OF SPEEDOMETER

Price €13.22
#16 38110-KPP-T01

HORN COMP. (TOP)

Price €37.60
#18 38301-MKJ-D01

TURN SIGNAL RELAY COMP. (LED)

Price €96.88
#19 38306-KK4-000

RUBBER D'DAMPER OF CENTER CLIGNOTANTE (MITSUBA)

Price €9.01
#20 38501-MKR-D11

POWER RELAY COMP. (MICRO ISO 4P) (PANASONIC)

Price €23.18
#21 38506-KZZ-900

COVER, RELAY (2P)

Price €6.76
#22 38770-K1T-E11

PGM-FI UNIT

Price €321.47
#24 38771-K1T-E10

SUSPENSION, PGM-FI UNIT

Price €18.94
#26 61104-428-010 i

BAND OF GUARD-BOUE FRONT (WHITE)

Price €12.07
#27 77208-KW7-900

RUBBER B, MOUNTING SEAT

Price €9.20
#28 77302-473-000

COLLAR, PILLION SEAT

Price €8.26
#29 90525-030-000 i

WASHER B OF FIXING SUPPORT OF HANDLEBAR

Price €6.80
#30 90650-KW3-000

WIRE BAND

Price €9.46
#31 90651-KV6-003 i

STRIPE, CABLE 165MM (BLACK)

Price €9.78
#32 91534-SWA-003

CLIP D'COUPLING (GRIS FONCE)

Price €12.65
#33 91535-TA0-003

CLIP D'COUPLING (BROWN FONCE)

Price €11.84
#34 91565-S0X-003

CLIP D'COUPLING (GREEN FONCE)

Price €6.83
#35 91565-SEL-003

CLIP D'COUPLING (BLACK)

Price €6.83
#36 91771-MKK-H11

CAP, FAUX (6P) (ROUGE)

Price €24.54
#37 92101-060204J i

BOLT HEX., 6X20

Price €1.81
#38 94050-06000 i

FLANGE NUT, 6MM

Price €0.79
#39 95701-0601008 i

FLANGE BOLT, 6X10

Price €1.08
#40 95701-0603000 i

FLANGE BOLT, 6X30

Price €1.42
#41 95701-0603208 i

FLANGE BOLT, 6X32

Price €1.25
#42 95701-0801208 i

FLANGE BOLT, 8X12

Price €1.42
#43 98200-41000

MINI-FUSE (10A)

Price €1.25
#44 98200-43000

MINI-FUSE (30A)

Price €1.85
#7 32100-K1T-E10

HARNESS, WIRE

Price €349.32
#8 32103-K1T-E10

SUB HARNESS, FR

Price €123.61
