RIGHT CRANKCASE COVER for CRF300LA EXTREME RED (R292) from 2025

RIGHT CRANKCASE COVER for CRF300LA EXTREME RED (R292) from 2025
Reference
Product name
#21 90012-KYJ-900

BOLT, FLANGE, 6X25 (NSHF)

Price €2.98
#36 94302-08140

PIN B, DOWEL, 8X14

Price €2.46
#25 90702-KFM-900 i

DOWEL PIN, 8X12

Price €3.97
#31 91301-KYJ-710

O-RING, 118X19

Price €1.44
#31 91301-KYJ-901

O-RING, 118X19 (ARAI)

Price €3.18
#35 94301-12160

PIN A, DOWEL, 12X16

Price €2.08
#1 11300-K1T-EB0

COVER ASSY, R CRANKCASE

Price €352.12
#2 11394-K87-A30 i

GASKET, R CRANKCASE COVER

Price €8.64
#3 15326-KT7-000

COLLAR, OIL PATH, 18MM

Price €5.71
#4 15410-K0A-DB1

ELEMENT, OIL FILTER

Price €12.05
#5 15411-K1T-EB0

COVER, OIL FILTER

Price €19.97
#6 15412-KYJ-901

GASKET, OIL FILTER COVER

Price €5.98
#7 15413-MC8-000

RUBBER, FILTER

Price €8.24
#8 15414-KF0-000

SPRING, OIL FILTER ELEMENT SETTING

Price €6.38
#9 15611-KA4-710

CAP, OIL FILLER

Price €24.01
#10 19120-KZZ-900

PIPE COMP, WATER

Price €15.74
#11 19215-KGH-900

IMPELLER, WATER PUMP

Price €5.60
#12 19217-P72-013 i

SEAL, MECHANICAL

Price €70.20
#13 19220-K1T-EB0

COVER COMP, WATER PUMP

Price €26.08
#14 19226-KYJ-710

GASKET, WATER PUMP COVER

Price €1.37
#15 19241-KZZ-D20 i

SHAFT, WATER PUMP

Price €14.04
#16 22810-K1T-EB0

LEVER COMP, CLUTCH

Price €11.24
#17 22815-KM7-700

SPRING, CLUTCH LEVER

Price €5.47
#18 22821-K1T-EB0

RECEIVER, CLUTCH CABLE

Price €8.92
#19 90010-KYJ-900

BOLT, FLANGE, 6X16 (NSHF)

Price €2.98
#20 90012-K64-N00

BOLT, FLANGE, 6X35 (NSHF)

Price €2.98
#22 90015-KYJ-900

BOLT, FLANGE, 6X65 (NSHF)

Price €2.98
#23 90423-KW6-900 i

WASHER, 7X13X12

Price €5.99
#24 90463-ML7-000 i

WASHER, SEALING, 65MM

Price €4.62
#26 91009-KYJ-711

BEARING, RADIAL BALL SPECIAL, 6001U

Price €10.76
#27 91015-KYJ-711

BEARING, RADIAL BALL, 6001

Price €8.06
#27 96100-6001300

BEARING, RADIAL BALL, 6001

Price €18.46
#28 91021-MKS-E01

BEARING, NEEDLE, 12X16X10

Price €24.22
#28 91022-KYJ-711

BEARING, NEEDLE, 12X16X10

Price €4.73
#29 91202-KTW-901

OIL SEAL, 12X26X5

Price €10.26
#30 91204-KK0-003 i

OIL SEAL, 12X18X5 (ARAI)

Price €5.14
#32 91302-KYJ-710

O-RING, 98X24

Price €1.27
#33 91307-035-000 i

O-RING, 18X3

Price €1.44
#34 91322-K0A-DB0

O-RING, 178X19

Price €3.18
