CRANKCASE for CRF250L EXTREME RED (R292) from 2015

CRANKCASE for CRF250L EXTREME RED (R292) from 2015
Reference
Product name
#1 11100-KZZ-900

CRANKCASE COMP, R

Price €613.18
#2 11107-KYJ-900

BOLT, SEALING, 16MM

Price €12.18
#3 11200-KZZ-900

CRANKCASE COMP, L

Price €611.33
#4 13312-KYJ-901

BEARING A, CRANKSHAFT (BLUE)

Price €30.90
#4 13313-KYJ-901

BEARING B, CRANKSHAFT (BLACK)

Price €33.05
#4 13314-KYJ-901

BEARING C, CRANKSHAFT (BROWN)

Price €29.81
#4 13315-KYJ-305

BEARING D, CRANKSHAFT (RED) (OS)

Price €38.04
#4 13316-KYJ-305

BEARING E, CRANKSHAFT (GREEN) (OS)

Price €38.04
#4 13317-KYJ-305

BEARING F, CRANKSHAFT (YELLOW) (OS)

Price €38.04
#4 13318-KYJ-305

BEARING G, CRANKSHAFT (PINK) (OS)

Price €21.66
#5 15421-KYJ-900

SCREEN, OIL FILTER

Price €13.61
#6 35600-HA0-003

SWITCH ASSY, NEUTRAL (TOYO)

Price €31.49
#7 37700-KZZ-901

SENSOR ASSY, SPEED

Price €155.62
#8 90014-KYJ-900

BOLT, FLANGE, 6X40 (NSHF)

Price €3.74
#9 90016-KYJ-900

BOLT, FLANGE, 6X70 (NSHF)

Price €5.02
#10 90032-KYJ-900

BOLT, STUD, 10X178

Price €6.80
#11 90061-KYJ-900

BOLT, DRAIN PLUG, 12MM

Price €8.76
#12 90443-KR0-000

WASHER, NEUTRAL SWITCH

Price €3.83
#13 91301-KYJ-901

O-RING, 118X19 (ARAI)

Price €3.34
#14 94109-12000

WASHER, DRAIN PLUG, 12MM

Price €1.74
#15 94301-12160

PIN A, DOWEL, 12X16

Price €2.04
#16 94302-08140

PIN B, DOWEL, 8X14

Price €2.41
#17 95701-0601800

BOLT, FLANGE, 6X18

Price €1.13
