STARTING MOTOR (CRF230F8/9/B) for CRF230F EXTREME RED (R292) from 2009

STARTING MOTOR (CRF230F8/9/B) for CRF230F EXTREME RED (R292) from 2009
Reference
Product name
#1 28110-KBB-900

GEAR COMP, STARTER DRIVEN (56T)

Price €93.67
#2 28114-KN6-930

COLLAR, STARTING DRIVEN GEAR

Price €13.51
Contact us
#3 28130-KFB-000

GEAR, REDUCTION (16T/61T)

Contact us
#4 28132-KPS-900

SHAFT, REDUCTION GEAR

Price €20.42
#5 28140-KPS-900

GEAR, IDLE (16T/16T)

Contact us
#6 28142-KW1-900

SHAFT, IDLE GEAR

Contact us
#7 31200-KPS-A11

MOTOR ASSY, STARTER (MITSUBA)

Price €787.62
Contact us
#8 31201-MEW-921

BRUSH SET A, CARBON

Price €18.38
#9 31202-MEW-921

BRUSH SET B, CARBON

Price €18.44
#10 31203-MEW-921

HOLDER, BRUSH

Price €10.15
#11 31204-MEW-921

SPRING, CARBON BRUSH

Price €4.56
#12 31205-HP5-601

BOLT, SETTING

Price €7.67
#13 31206-MEW-921

BOLT, TERMINAL

Price €8.65
#14 31207-HP5-601

RING

Price €4.56
#15 31208-MEW-921

INSULATOR

Price €3.98
#16 31209-MEW-921

STOPPER, TERMINAL

Price €9.94
#17 31210-MEW-921

WASHER

Price €3.40
#18 90036-GHR-730

BOLT, FLANGE, 6X32

Price €1.15
#19 90071-MB0-000

NUT-WASHER, 6MM

Price €5.28
#20 91309-425-003

O-RING, 244X31 (ARAI)

Price €8.52
#21 91320-MB0-000

O-RING, 4X2

Price €5.23
#22 93892-0501208

SCREW-WASHER, 5X12

Price €1.32
