FUEL TANK for CRF125FB EXTREME RED (R292) from 2023

FUEL TANK for CRF125FB EXTREME RED (R292) from 2023
Reference
Product name
#1 16700-K28-A61

PUMP UNIT ASSY, FUEL

Price €541.27
#2 16707-K45-N01

FILTER SET

Price €138.49
#3 16711-K99-A01

O-RING, 37X629

Price €30.28
#4 17500-K28-A60

TANK ASSY, FUEL

Price €613.88
#5 17509-KYK-910

COLLAR, TANK MOUNTING

Price €1.94
#6 17515-MJE-D00

TRIM, FUEL TANK

Price €40.81
#7 17527-K28-A60

PLATE COMP, SETTING

Contact us
#8 17530-K28-A60

TRAY, FUEL

Price €27.73
#9 17540-K28-AG0ZA

SHROUD SET A, R TANK (WL) R292R (R292R EXTREME...

Price €227.87
#10 17546-K28-A60

SHROUD B, R

Price €39.86
#11 17550-K28-AG0ZA

SHROUD SET A, L TANK (WL) R292R (R292R EXTREME...

Price €274.06
#12 17556-K28-910

FILM, PROTECTOR

Price €7.19
#13 17556-K28-A60

SHROUD B, L

Price €14.84
#14 17560-K28-A60

COVER, CENTER TANK

Price €49.13
#15 17571-K28-A61

HOSE COMP, FUEL FEED

Price €34.70
#16 17574-K99-A01

SEAL, DUST

Price €11.29
#17 17575-K99-A00

COVER, FUEL CONNECTOR

Price €18.52
#18 17576-KRN-A90

RUBBER, FUEL CONNECTOR

Price €12.94
#19 17620-K28-M21

CAP COMP, FUEL FILLER

Price €171.14
#20 50329-KYA-B00

RUBBER, RR CARRIER MOUNTING

Price €2.96
#21 83551-376-000

GROMMET, SIDE COVER

Price €5.86
#22 90126-K99-A00

BOLT, SPECIAL, 6MM

Price €1.18
#23 90502-MEN-A30

WASHER, CONICAL SPRING FUEL PUMP

Price €7.20
#24 90503-K99-A00

COLLAR, FUEL PUMP

Price €5.44
#25 90504-K28-A60

COLLAR, TANK FR

Price €4.27
#26 90653-HC4-900

CLIP, MUDGUARD

Price €0.73
#27 93913-24120

SCREW, TAPPING, 4X10

Price €0.77
#28 95701-0601600

BOLT, FLANGE, 6X16

Price €1.15
#29 95701-0801600

BOLT, FLANGE, 8X16

Price €1.31
#30 95701-0802500

BOLT, FLANGE, 8X25

Price €1.57
