REAR CUSHION for CR125R EXPLOSION RED (R254) from 2003

REAR CUSHION for CR125R EXPLOSION RED (R254) from 2003
Reference
Product name
#1 41405-HA7-670

RING, STOPPER

Price €7.08
#2 51453-KK0-004

CAP, AIR VALVE

Price €8.05
#6 52421-KZ4-L21

ROD COMP, PISTON

Contact us
#7 52422-KS6-701

SEAT, UPPER SPRING

Price €45.96
#8 52422-KZ4-J31

WASHER, SPRING SEAT

Price €8.76
Contact us
#9 52423-KS6-701

NUT, ADJUSTER

Price €38.16
#10 52424-KZ4-J11

SEAT, SPRING LOWER

Price €8.59
Contact us
#11 52425-KZ4-L21

CASE COMP, RR

Contact us
#12 52426-KZ4-J41

ROD COMP

Price €517.04
Contact us
#13 52427-KZ4-J31

RUBBER, BUMPER

Price €27.59
#14 52428-KZ4-901

CAP, CASE

Price €29.80
Contact us
#15 52429-KZ4-901

CASE COMP, ROD GUIDE

Price €49.91
#16 52431-MAC-681

RING, PISTON

Price €29.89
#17 52432-KZ4-901

O-RING, 375X20

Price €11.18
#18 52433-MAC-741

O-RING, 215X15

Price €5.58
#19 52434-KZ4-901

O-RING, 397X35

Price €10.76
Contact us
#20 52435-MAC-741

O-RING, 255X20

Price €7.57
#21 52437-KA3-731

CORE, VALVE

Price €22.72
#22 52438-KA3-731

NUT, HEX, 12MM

Price €6.53
#23 52440-KZ4-A91

ADJUSTER, COMPRESSION DAMPING FORCE

Price €122.35
Contact us
#24 52451-KZ4-901

BLADDER

Price €46.44
#25 52452-KZ4-003

RING, SNAP

Price €7.86
Contact us
#26 52453-KZ4-003

CAP, BLADDER

Price €81.67
#27 52463-KZ4-B00

COLLAR D, CUSHION

Price €6.94
#28 52463-KZ4-J40

COLLAR C, CUSHION ARM

Price €18.22
#29 52464-KZ4-B00

COLLAR D, CUSHION SIDE

Price €7.48
#30 52464-KZ4-J20

COLLAR B, CUSHION

Price €19.62
#31 52465-KZ4-J40

ARM SUB ASSY, CUSHION

Price €471.97
Contact us
#32 52473-KZ4-J20

COLLAR A, CONNECTING ROD

Price €37.88
#33 52475-KZ4-J20

COLLAR, LINK SIDE

Price €19.27
#34 52476-KZ4-J20

WASHER, THRUST

Price €16.66
#35 52479-KZ4-J40

ROD SUB ASSY, CUSHION CONNECTING

Price €172.73
Contact us
#36 87516-KZ1-600

LABEL, RR DAMPER WARNING

Price €15.01
#37 90130-KZ4-J20

BOLT, LINK, 12X96

Price €25.15
#38 90130-KZ4-J40

BOLT, LINK, 12X815

Price €24.64
#39 90131-KZ4-J40

BOLT, LINK, 12X120

Price €31.56
Contact us
#40 90153-KZ4-710

BOLT, CUSHION LOWER, 10X435

Price €9.20
#41 90306-KBP-901 i

NUT, U, 12MM

Price €13.76
#42 90306-KZ4-711

NUT, U, 10MM

Price €7.45
#52 90501-KZ4-J40

WASHER, PLAIN, 12MM

Price €7.48
#53 91053-KZ4-J21 i

BEARING, NEEDLE, 20X26X14

Price €26.62
#45 91074-KZ4-B01

BEARING, NEEDLE, 19X26X15

Price €43.38
#46 91074-MAC-741

BEARING, SPHERICAL, 10

Price €43.39
#47 91262-KZ3-731

DUST SEAL, 25X32X4

Price €9.06
#48 91351-KZ3-731 i

DUST SEAL, RR CUSHION PIVOT

Price €4.88
#49 91351-KZ4-B01

DUST SEAL, 17X26X3

Price €6.32
#50 91351-MAC-671 i

DUST SEAL, 16X26X3

Price €5.18
#51 87516-KZ1-881 i

LABEL, RR DAMPER WARNING (FRENCH)

Price €15.01
#3 52400-KZ4-L31

CUSHION ASSY, RR (KAYABA)

Contact us
#4 52401-KZ4-J01

SPRING, RR CUSHION (KAYABA) (450N/MM,46KGF/MM)

Contact us
#4 52402-KZ4-J01

SPRING, RR CUSHION (KAYABA) (430N/MM,44KGF/MM)

Price €347.20
#4 52403-KZ4-J01

SPRING, RR CUSHION (KAYABA) (470N/MM,48KGF/MM)

Price €241.00
Contact us
#4 52404-KZ4-J01

SPRING, RR CUSHION (KAYABA) (49N/MM,50KGF/MM)

Price €252.52
#5 52410-KZ4-L31

DAMPER COMP, RR

Contact us
