PEDAL for CMX500 CANDY DIESEL RED (R326) from 2023

PEDAL for CMX500 CANDY DIESEL RED (R326) from 2023
Reference
Product name
#1 24710-MGZ-J00

ARM COMP, GEAR CHANGE

Price €147.28
#2 24720-MKG-A00

PEDAL COMP, GEAR CHANGE

Price €81.53
#3 24724-MBW-D21

COVER, DUST

Price €19.44
#4 24731-K87-A00

COLLAR, GEAR CHANGE PEDAL PIVOT

Price €11.23
#5 24781-KR3-770

RUBBER, GEAR CHANGE PEDAL

Price €9.32
#6 35350-K87-A01

SWITCH ASSY, RR STOP (TOYO DENSO)

Price €61.86
#7 35357-K26-900

SPRING, STOP SWITCH

Price €6.20
#8 46501-K87-A30

PEDAL COMP, RR BRAKE

Price €98.20
#9 46514-K87-A00

SPRING, BRAKE PEDAL

Price €4.58
#10 90110-K87-A00

BOLT, SOCKET SPECIAL, 8X45

Price €7.91
#11 90165-MKG-A00

BOLT, TIE ROD

Price €43.66
#12 90301-MGZ-J00

NUT, SPECIAL, 6MM (LEFT HAND THREAD)

Price €5.59
#13 90451-GBL-870

WASHER, 14MM

Price €5.22
#14 90526-K87-A00

WASHER, 85X20

Price €3.71
#15 94001-060700S

NUT, HEX, 6MM

Price €0.86
#16 94101-08000

WASHER, PLAIN, 8MM

Price €0.72
#17 94511-14000

CIRCLIP, EXTERNAL, 14MM

Price €0.86
#18 95701-0602007

BOLT, FLANGE, 6X20

Price €1.13
