PEDAL for CMX1100 PEARL HAWKSEYE BLUE (PB409) from 2025

PEDAL for CMX1100 PEARL HAWKSEYE BLUE (PB409) from 2025
Reference
Product name
#1 24706-MK3-770

RUBBER, DUST SEAL

Price €8.11
#2 24710-MLA-A00

ARM COMP, GEAR CHANGE

Price €153.05
#3 24720-MLA-AA0

PEDAL COMP, GEAR CHANGE

Price €264.54
#4 24724-MBW-D21

COVER, DUST

Price €19.44
#5 24781-KR3-770

RUBBER, GEAR CHANGE PEDAL

Price €9.32
#6 35350-MLA-A01

SWITCH ASSY, RR STOP &amp CRUISE

Price €119.95
#7 35357-MLA-AA0

SPRING, STOP SWITCH

Price €15.20
#8 46501-MLA-A00

PEDAL COMP, RR BRAKE

Price €64.69
#9 46514-MLA-A00

SPRING, BRAKE PEDAL

Price €8.17
#10 90031-GHB-660

BOLT, FLANGE, 6X20

Price €6.71
#11 90115-KAF-000

BOLT, CHANGE PIVOT

Price €16.34
#12 90165-MLA-AA0

BOLT, TIE ROD

Price €13.94
#13 90301-MGZ-J00

NUT, SPECIAL, 6MM (LEFT HAND THREAD)

Price €5.59
#14 90557-230-000

WASHER, 152X25

Price €6.56
#15 90690-MEF-800

CLAMP, HARNESS

Price €4.45
#16 94001-060700S

NUT, HEX, 6MM

Price €0.86
#17 94103-08700

WASHER, PLAIN, 8MM

Price €0.62
#18 94201-30250

PIN, SPLIT, 30X25

Price €0.78
#19 94511-15000

CIRCLIP, EXTERNAL, 15MM

Price €0.91
