STEP (CMX1100A2/D2) for CMX1100 IRIDIUM GRAY METALLIC (NHC65) from 2025

STEP (CMX1100A2/D2) for CMX1100 IRIDIUM GRAY METALLIC (NHC65) from 2025
Reference
Product name
#1 28333-300-000

SPRING, KICK STARTER STOPPER

Price €6.22
#2 50603-GS9-010

PIN, MAIN STEP BAR JOINT (PILLION)

Price €10.08
#3 50607-MLA-A00

GUARD, R STEP

Price €22.43
#4 50608-MLA-A00

GUARD, L STEP

Price €22.49
#5 50612-MLA-A00

ARM, R MAIN STEP

Price €188.51
#6 50617-445-840

SPRING, R STEP RETURN

Price €8.14
#7 50639-ML0-010

PIN, STEP BAR

Price €6.24
#8 50642-MLA-A00

ARM, L MAIN STEP

Price €168.56
#9 50644-445-840

SPRING, L STEP RETURN

Price €8.54
#10 50650-MLA-AA0

HOLDER, R STEP

Price €605.57
#11 50651-MLA-A00

STAY COMP, BRAKE SWITCH

Price €43.32
#12 50711-MLA-J00

ARM, R PILLION STEP

Price €145.68
#13 50712-MLA-J00

ARM, L PILLION STEP

Price €145.68
#14 50715-MLA-A30

HOLDER, R PILLION STEP

Price €423.85
#15 50716-K87-A00

BRACKET, PILLION STEP

Price €72.85
#16 50717-MLA-J30

BOLT, PILLION STEP BRACKET

Price €15.95
#17 50718-MN8-000

PLATE, PILLION STEP CLICK

Price €8.36
#18 50725-MLA-A30

HOLDER, L PILLION STEP

Price €442.81
#19 50735-MLA-J30

GUARD COMP, MUFFLER

Price €120.50
#20 50750-MLA-AA0

HOLDER, L STEP

Price €610.73
#21 90036-GHB-760

BOLT, FLANGE, 8X50

Price €7.50
#22 90154-MLA-A00

BOLT, SOCKET, 5X12

Price €7.10
#23 90157-MLA-A00

BOLT, SOCKET, 8X22

Price €9.07
#24 90203-MF9-710

NUT, SIDE STAND

Price €6.91
#25 90506-MLA-AA0

COLLAR, 63X125X15

Price €8.82
#26 90751-K87-A00

PIN, SPRING, 3X8

Price €4.02
#27 92501-060250G

BOLT, CAP, 6X25

Price €2.80
#28 94102-08000

WASHER, PLAIN, 8MM

Price €1.21
#29 94201-20151

PIN, SPLIT, 20X15

Price €0.62
#30 96211-08000

BALL, STEEL, 8 (1/4)

Price €0.44
