FUEL TANK/FUEL PUMP (CL500AP/R) for CL500A MAT GUNPOWDER BLACK METALLIC (NH436) from 2023

FUEL TANK/FUEL PUMP (CL500AP/R) for CL500A MAT GUNPOWDER BLACK METALLIC (NH436) from 2023
Reference
Product name
#1 16700-MLP-AA1

PUMP UNIT, FUEL

Price €681.16
#2 16711-MGS-D31

STOPPER

Price €10.08
#3 16712-MGS-D31

SCREW, 4X66

Price €6.79
#4 16730-MKT-D01

FILTER ASSY, FUEL

Price €78.19
#6 17508-K3S-JA0

FILM, TANK PROTECTOR

Price €16.73
#7 17570-MKG-A01

HOSE COMP, FUEL FEED

Price €209.77
#8 17571-K3S-JA0

PAD COMP, R TANK

Price €133.97
#9 17574-MGS-D30

PACKING, BASE

Price €32.47
#10 17576-K3S-JA0

PAD COMP, L TANK

Price €133.97
#11 17580-MKG-A00

GUARD, FUEL PUMP

Price €22.46
#12 17611-KPK-900

CUSHION, FUEL TANK FR

Price €3.71
#13 17613-K3S-JA0

CUSHION, FUEL TANK RR

Price €20.36
#14 17620-K3S-JA1

CAP COMP, FUEL FILLER

Price €136.00
#15 17621-MGP-D62

SEAL, BREATHER

Price €10.20
#16 90120-MJE-D00

BOLT, SOCKET, 4X25 (SUS)

Price €10.90
#17 90201-415-000

NUT, CAP, 6MM

Price €5.94
#18 90304-KZZ-900

NUT, HEX CAP, 6MM

Price €12.11
#19 90502-K87-A00

WASHER, 85X26

Price €2.32
#20 91593-MGZ-J01

CLAMP, FUEL HOSE (BLACK)

Price €5.15
#21 95005-8089020

TUBE (8X890)

Price €78.44
#22 95701-0802207

BOLT, FLANGE, 8X22

Price €1.70
#5 17500-MLP-AA0ZA

TANK ASSY, FUEL (WL) TYPE6 (TYPE6 )

Price €726.04
