CRANKCASE 🏍️ CBR500R
TRANSMISSION (MAINSHAFT) 🏍️ CBR500R

CRANKSHAFT/PISTON for CBR500R LEMON ICE YELLOW (Y196) from 2016

CRANKSHAFT/PISTON for CBR500R LEMON ICE YELLOW (Y196) from 2016
Reference
Product name
# 11000-MGZ-J01

CRANKCASE SET

Price €2,257.91
# 11103-MGZ-J00

PIN, PARTITION

Price €5.80
# 11140-MGZ-J00

JET COMP, OIL

Price €23.60
# 12207-KYJ-900

BOLT, SEALING, 12MM

Price €3.25
# 15515-MGZ-J00

ORIFICE A, 10MM

Price €3.16
# 19060-MGZ-J00

JOINT, WATER

Price €22.48
# 32101-MJW-J00

SUB HARNESS, ENGINE

Price €36.90
# 32102-MJW-J00

SUB HARNESS, OIL PRESSURE

Price €17.26
# 32157-MGZ-J00

STAY, HARNESS CLIP

Price €5.00
# 35500-MEH-661

SWITCH ASSY, OIL PRESSURE (DENSO)

Price €82.79
# 35600-MK4-860

SWITCH ASSY, NEUTRAL

Price €43.04
# 37700-MJE-D01

SENSOR ASSY, SPEED (TDK-EPC)

Price €47.42
# 90002-PA6-003

BOLT-WASHER, 4X8 (DENSO)

Price €6.14
# 90005-MAZ-000

BOLT, SOCKET, 10MM

Price €5.71
# 90009-MGZ-J00

BOLT, SOCKET, 10MM

Price €9.90
# 90015-MGZ-J01

BOLT, UBS, 8X105

Price €15.95
# 90048-MY5-600

BOLT, SEALING, 18MM

Price €17.57
# 90442-028-000

WASHER, SEALING, 8MM

Price €5.71
# 90443-MJ6-000

WASHER, NEUTRAL

Price €5.02
# 90463-ML7-000 i

WASHER, SEALING, 65MM

Price €4.62
# 90701-MV9-670

DOWEL PIN, 10X16

Price €7.63
# 91303-KF0-003 i

O-RING, 148X24 (ARAI)

Price €6.06
# 91304-MCP-900

O-RING, 23X24

Price €7.57
# 91305-MCJ-751 i

O-RING, 32X11

Price €4.98
# 92900-060160E

BOLT, STUD, 6X16

Price €1.98
# 94050-04000 i

NUT, FLANGE, 4MM

Price €0.88
# 94050-06000 i

NUT, FLANGE, 6MM

Price €0.79
# 95701-0601200 i

BOLT, FLANGE, 6X12

Price €1.15
# 95701-0601800 i

BOLT, FLANGE, 6X18

Price €1.15
# 95701-0603500 i

BOLT, FLANGE, 6X35

Price €1.34
# 95701-0604008 i

BOLT, FLANGE, 6X40

Price €1.34
# 95701-0609500

BOLT, FLANGE, 6X95

Price €3.06
# 95701-0805500 i

BOLT, FLANGE, 8X55

Price €2.87
# 95701-0807500

BOLT, FLANGE, 8X75

Price €3.06
# 95701-1007500 i

BOLT, FLANGE, 10X75

Price €3.73
# 96001-0601407 i

BOLT, FLANGE, 6X14

Price €1.34
#1 13011-MEE-305

RING SET, PISTON (STD)

Price €107.30
#1 13021-MEE-305

RING SET, PISTON (025)

Price €96.43
#2 13101-MGZ-D00

PISTON (STD)

Price €42.38
#2 13102-MGZ-305

PISTON (025)

Price €90.58
#3 13111-MFG-D00

PIN, PISTON

Price €36.26
#4 13115-MGZ-J00

CLIP, PISTON PIN, 16MM

Price €4.90
#5 13210-MGZ-D00

ROD ASSY, CONNECTING

Price €114.89
#6 13213-ML7-020 i

BOLT, CONNECTING ROD

Price €11.96
#7 13214-MGZ-J01

BEARING A, CONNECTING ROD (BLUE)

Price €32.82
#7 13215-MGZ-J01

BEARING B, CONNECTING ROD (BLACK)

Price €32.82
#7 13216-MGZ-J01

BEARING C, CONNECTING ROD (BROWN)

Price €32.82
#7 13217-MGZ-J01

BEARING D, CONNECTING ROD (GREEN)

Price €32.82
#7 13218-MGZ-J01

BEARING E, CONNECTING ROD (YELLOW)

Price €32.82
#8 13215-ML7-000

NUT, CONNECTING ROD

Price €10.28
#9 13300-MGZ-D01 i

CRANKSHAFT COMP

Price €1,400.71
#10 13313-MW0-003

BEARING A, CRANKSHAFT (BLACK)

Price €24.20
#10 13314-MW0-003

BEARING B, CRANKSHAFT (BROWN)

Price €24.20
#10 13315-MW0-003 i

BEARING C, CRANKSHAFT (GREEN)

Price €24.20
#10 13316-MW0-003 i

BEARING D, CRANKSHAFT (YELLOW)

Price €24.20
#10 13317-MW0-003

BEARING E, CRANKSHAFT (PINK)

Price €24.20
#11 13420-MGZ-D01

SHAFT COMP, BALANCER (40T)

Price €951.58
#12 14311-MGZ-J00

SPROCKET, TIMING (17T)

Price €18.67
#13 23113-MGZ-J00

GEAR, PRIMARY DRIVE (34T)

Price €235.08
#14 23114-MGZ-J00

SUB GEAR, PRIMARY (34T)

Price €55.86
#15 23115-MV1-300

SPRING, PRIMARY DRIVE GEAR

Price €4.88
#16 90013-MGZ-J00

BOLT, SPECIAL, 10X25

Price €2.98
#17 90405-MGZ-J00

WASHER, 105X40

Price €12.68
#18 90742-KYJ-900

KEY, WOODRUFF, 25X18

Price €5.94
#19 91001-MGZ-J00

BEARING, SPECIAL RADIAL BALL, 6204

Price €33.05
