TRANSMISSION (MAINSHAFT) for CBR500R GRAND PRIX RED (R380) from 2024

TRANSMISSION (MAINSHAFT) for CBR500R GRAND PRIX RED (R380) from 2024
Reference
Product name
#1 23211-MKP-D00

MAINSHAFT (14T)

Price €99.60
#2 23212-MGZ-J00

PLATE, BEARING SETTING

Price €23.99
#3 23431-MKP-D00

GEAR, MAINSHAFT SECOND (19T)

Price €46.36
#4 23451-MKP-D00

GEAR, MAINSHAFT THIRD &amp FOURTH (20T/20T)

Price €102.13
#5 23491-MKP-D00

GEAR, MAINSHAFT FIFTH (20T)

Price €63.00
#6 23492-MGZ-J00

COLLAR, 25X28X12

Price €23.64
#7 23511-MKP-D00

GEAR, MAINSHAFT SIXTH (23T)

Price €62.64
#8 23512-MV9-670

COLLAR, SPLINE, 25X28X13

Price €32.23
#9 23531-MGZ-J00

PLATE, BEARING SETTING

Price €9.55
#10 90005-MGZ-J00

BOLT, FLANGE, 6X14 (NSHF)

Price €2.98
#11 90403-KE7-000

WASHER, THRUST, 172MM

Price €7.20
#12 90451-KY2-000

WASHER, SPLINE, 25X31X15

Price €7.48
#13 90454-KYJ-900

WASHER, SPLINE, 25X42X16

Price €8.92
#14 90455-KYJ-900

WASHER, LOCK, 25MM

Price €56.69
#15 90456-MA6-000

WASHER, THRUST, 25MM

Price €7.61
#16 90601-107-000

CIRCLIP, 25MM

Price €7.91
#17 91022-MN4-003

BEARING, NEEDLE, 17X27X148 (TOYO)

Price €26.09
#18 91023-MN4-003 i

OUTER, NEEDLE BEARING

Price €34.56
#19 95701-0601400 i

BOLT, FLANGE, 6X14

Price €1.15
#20 96100-6305000 i

BEARING, RADIAL BALL, 6305

Price €28.32
# 06112-MLR-D00

GASKET KIT B

Price €36.17
# 14560-MGZ-J01

GASKET, TENSIONER HOLE

Price €4.92
# 15154-MAT-000

PACKING, OIL STRAINER

Price €11.04
# 37501-K2Y-J01

O-RING

Price €6.30
# 90442-028-000

WASHER, SEALING, 8MM

Price €5.71
# 90442-397-000

WASHER, SEALING, 6MM

Price €7.07
# 90463-MEE-000

WASHER, SEALING, 6MM

Price €6.26
# 90463-ML7-000 i

WASHER, SEALING, 65MM

Price €4.62
# 91301-ML7-003

O-RING, 481X36 (ARAI)

Price €7.22
# 91302-MB0-013 i

O-RING, 3295X262 (ARAI)

Price €6.30
# 91303-KF0-003 i

O-RING, 148X24 (ARAI)

Price €6.06
# 91304-MCP-900

O-RING, 23X24

Price €7.57
# 91305-KC1-850

O-RING, 165X25

Price €6.06
# 91305-MCJ-751 i

O-RING, 32X11

Price €4.98
# 91307-035-000 i

O-RING, 18X3

Price €1.44
# 91309-425-003 i

O-RING, 244X31 (ARAI)

Price €12.66
# 91313-MB0-003 i

O-RING, 147X22 (ARAI)

Price €9.58
# 94109-12000 i

WASHER, DRAIN PLUG, 12MM

Price €1.78
