STARTER MOTOR for CBR500R GRAND PRIX RED (R380) from 2024

STARTER MOTOR for CBR500R GRAND PRIX RED (R380) from 2024
Reference
Product name
#1 31200-MGZ-J01

MOTOR ASSY, STARTER (MITSUBA)

Price €399.31
#2 31201-MEW-921

BRUSH SET A, CARBON

Price €18.88
#3 31202-MEW-921

BRUSH SET B, CARBON

Price €18.88
#4 31203-MEW-921

HOLDER, BRUSH

Price €13.49
#5 31204-MEW-921

SPRING, CARBON BRUSH

Price €6.92
#6 31205-HP5-601

BOLT, SETTING

Price €7.91
#7 31206-MEW-921

BOLT, TERMINAL

Price €6.38
#8 31207-HP5-601

RING

Price €6.80
#9 31208-MEW-921

INSULATOR

Price €5.58
#10 31209-MEW-921

STOPPER, TERMINAL

Price €12.14
#11 31210-MEW-921

WASHER

Price €5.44
#12 32410-MKP-DN0

CABLE, STARTER MOTOR

Price €29.30
#13 32601-MKP-DN0

CABLE, BATTERY EARTH

Price €33.12
#14 61309-GE4-003

CLIP, HARNESS

Price €8.05
#15 90071-MB0-000 i

NUT-WASHER, 6MM

Price €6.12
#16 91309-425-003 i

O-RING, 244X31 (ARAI)

Price €12.66
#17 91320-MB0-000

O-RING, 4X2

Price €5.34
#18 93892-0501208 i

SCREW-WASHER, 5X12

Price €1.34
#19 95801-0602808

BOLT, FLANGE, 6X28

Price €1.04
# 06112-MLR-D00

GASKET KIT B

Price €36.17
# 14560-MGZ-J01

GASKET, TENSIONER HOLE

Price €4.92
# 15154-MAT-000

PACKING, OIL STRAINER

Price €11.04
# 37501-K2Y-J01

O-RING

Price €6.30
# 90442-028-000

WASHER, SEALING, 8MM

Price €5.71
# 90442-397-000

WASHER, SEALING, 6MM

Price €7.07
# 90463-MEE-000

WASHER, SEALING, 6MM

Price €6.26
# 90463-ML7-000 i

WASHER, SEALING, 65MM

Price €4.62
# 91301-ML7-003

O-RING, 481X36 (ARAI)

Price €7.22
# 91302-MB0-013 i

O-RING, 3295X262 (ARAI)

Price €6.30
# 91303-KF0-003 i

O-RING, 148X24 (ARAI)

Price €6.06
# 91304-MCP-900

O-RING, 23X24

Price €7.57
# 91305-KC1-850

O-RING, 165X25

Price €6.06
# 91305-MCJ-751 i

O-RING, 32X11

Price €4.98
# 91307-035-000 i

O-RING, 18X3

Price €1.44
# 91313-MB0-003 i

O-RING, 147X22 (ARAI)

Price €9.58
# 94109-12000 i

WASHER, DRAIN PLUG, 12MM

Price €1.78
