GEARSHIFT DRUM for CBR300RA NOIR (NH1) from 2016

GEARSHIFT DRUM for CBR300RA NOIR (NH1) from 2016
Reference
Product name
#1 11300-K33-D01 i

COVER ASSY, R CRANKCASE

Price €282.10
#2 11394-KYJ-900 i

GASKET, R CRANKCASE COVER

Price €8.64
#3 15326-KT7-000

COLLAR, OIL PATH, 18MM

Price €5.71
#4 15410-KYJ-901 i

ELEMENT, OIL FILTER

Price €12.05
#5 15411-KYJ-900

COVER, OIL FILTER

Price €15.71
#6 15412-KYJ-901

GASKET, OIL FILTER COVER

Price €5.98
#7 15413-MC8-000

RUBBER, FILTER

Price €8.24
#8 15414-KF0-000

SPRING, OIL FILTER ELEMENT SETTING

Price €6.38
#9 15611-KA4-710

CAP, OIL FILLER

Price €24.01
#10 19120-KYJ-900

PIPE COMP, WATER

Price €16.03
#11 19215-KGH-900

IMPELLER, WATER PUMP

Price €5.60
#12 19217-P72-013 i

SEAL, MECHANICAL

Price €70.20
#13 19220-KYJ-900

COVER COMP, WATER PUMP

Price €39.23
#14 19226-KYJ-901

GASKET, WATER PUMP COVER (ARAI)

Price €2.47
#15 19241-KYJ-900 i

SHAFT, WATER PUMP

Price €14.04
#16 22810-K33-D00

LEVER COMP, CLUTCH

Price €45.77
Contact us
#17 22815-KM7-700

SPRING, CLUTCH LEVER

Price €5.47
#18 22821-K33-D00

RECEIVER, CLUTCH CABLE

Price €19.49
Contact us
#19 90010-KYJ-900

BOLT, FLANGE, 6X16 (NSHF)

Price €2.98
#20 90012-KYJ-900

BOLT, FLANGE, 6X25 (NSHF)

Price €2.98
#21 90013-KYJ-900

BOLT, FLANGE, 6X30 (NSHF)

Price €2.98
#22 90015-KYJ-900

BOLT, FLANGE, 6X65 (NSHF)

Price €2.98
#23 90423-KW6-900 i

WASHER, 7X13X12

Price €5.99
#24 90463-ML7-000 i

WASHER, SEALING, 65MM

Price €4.62
#25 90702-KFM-900 i

DOWEL PIN, 8X12

Price €3.97
#26 91009-KYJ-901

BEARING, RADIAL BALL SPECIAL, 6001U

Price €21.85
#27 91053-719-005 i

BEARING, NEEDLE, 12X16X10 (NTN)

Price €25.51
#28 91204-KK0-003 i

OIL SEAL, 12X18X5 (ARAI)

Price €5.14
#29 91205-KF0-003 i

OIL SEAL, 12X20X5 (ARAI)

Price €5.57
#30 91301-KYJ-901

O-RING, 118X19 (ARAI)

Price €3.18
#31 91302-KYJ-901

O-RING, 98X24 (ARAI)

Price €3.18
#32 91307-035-000 i

O-RING, 18X3

Price €1.44
#33 91322-PT0-004 i

O-RING, 178X19 (ARAI)

Price €3.44
Contact us
#34 94301-12160

PIN A, DOWEL, 12X16

Price €2.08
#35 94302-08140

PIN B, DOWEL, 8X14

Price €2.46
#36 96100-6001300

BEARING, RADIAL BALL, 6001

Price €18.46
