FRONT BRAKE MASTER CYLINDER (CBR250R) for CBR250R NITRIC ORANGE (YR271) from 2013

FRONT BRAKE MASTER CYLINDER (CBR250R) for CBR250R NITRIC ORANGE (YR271) from 2013
Reference
Product name
#1 35340-MM5-600

SWITCH ASSY, FR STOP

Price €44.35
#2 45125-KYJ-D21

HOSE COMP, FR BRAKE

Price €90.54
#3 45155-KYJ-900

CLAMPER, FR BRAKE HOSE

Price €4.78
#4 45156-KYJ-900

STAY, BRAKE HOSE CLAMP

Price €15.70
#5 45157-KYJ-900

CLAMPER B, FR BRAKE HOSE

Price €4.78
#6 45504-410-003

BOOT COMP

Price €15.22
#7 45510-KYJ-D21

CYLINDER SUB ASSY, FR BRAKE MASTER

Price €361.01
#8 45512-MA6-006

PROTECTOR

Price €74.21
#9 45513-HA2-006

CAP, MASTER CYLINDER

Price €43.54
#10 45517-166-006

HOLDER, MASTER CYLINDER

Price €22.57
#11 45520-MG7-006

DIAPHRAGM

Price €24.06
#12 45521-HA2-006

PLATE, DIAPHRAGM

Price €13.94
#13 45530-KVY-911

CYLINDER SET, MASTER (NISSIN)

Price €39.05
#14 53174-116-670

PLUG, HANDLE LEVER BRACKET

Price €5.58
#15 53175-KPP-T01

LEVER, R STEERING HANDLE

Price €29.26
#16 90114-166-006

BOLT, HANDLE LEVER PIVOT

Price €8.58
#17 90145-MS9-612

BOLT, OIL, 10X22 (SAGA)

Price €13.14
#18 90545-300-000

WASHER, OIL BOLT

Price €6.41
#19 90651-MA5-671

CIRCLIP

Price €5.83
#20 93600-040121G

SCREW, FLAT, 4X12

Price €0.76
#21 93893-0401217

SCREW-WASHER, 4X12

Price €1.06
#22 94050-06000

NUT, FLANGE, 6MM

Price €0.78
#23 96001-0601207

BOLT, FLANGE, 6X12

Price €1.22
#24 96001-0602207

BOLT, FLANGE, 6X22

Price €1.70
