CRANKCASE for CBR250R NITRIC ORANGE (YR271) from 2013

CRANKCASE for CBR250R NITRIC ORANGE (YR271) from 2013
Reference
Product name
#1 11100-KYJ-900

CRANKCASE COMP, R

Price €486.16
#2 11107-KYJ-900

BOLT, SEALING, 16MM

Price €6.32
#3 11200-KYJ-900

CRANKCASE COMP, L

Price €410.32
#4 13312-KYJ-901

BEARING A, CRANKSHAFT (BLUE)

Price €32.16
#4 13313-KYJ-901

BEARING B, CRANKSHAFT (BLACK)

Price €32.16
#4 13314-KYJ-901

BEARING C, CRANKSHAFT (BROWN)

Price €32.16
#4 13315-KYJ-305

BEARING D, CRANKSHAFT (RED) (OS)

Price €32.16
#4 13316-KYJ-305

BEARING E, CRANKSHAFT (GREEN) (OS)

Price €32.16
#4 13317-KYJ-305

BEARING F, CRANKSHAFT (YELLOW) (OS)

Price €32.16
#4 13318-KYJ-305

BEARING G, CRANKSHAFT (PINK) (OS)

Price €32.16
#5 15421-KYJ-900

SCREEN, OIL FILTER

Price €7.99
#6 35600-425-023 i

SWITCH ASSY, NEUTRAL

Price €45.59
#7 37700-KYJ-901

SENSOR ASSY, SPEED

Price €118.33
#8 90014-KYJ-900

BOLT, FLANGE, 6X40 (NSHF)

Price €2.98
#9 90016-KYJ-900

BOLT, FLANGE, 6X70 (NSHF)

Price €2.98
#10 90032-KYJ-900

BOLT, STUD, 10X178

Price €5.83
#11 90061-KYJ-900

BOLT, DRAIN PLUG, 12MM

Price €2.98
#12 90443-KR0-000

WASHER, NEUTRAL SWITCH

Price €5.02
#13 91301-KYJ-901

O-RING, 118X19 (ARAI)

Price €3.18
#14 94109-12000 i

WASHER, DRAIN PLUG, 12MM

Price €1.78
#15 94301-12160

PIN A, DOWEL, 12X16

Price €2.08
#16 94302-08140

PIN B, DOWEL, 8X14

Price €2.46
#17 95701-0601800 i

BOLT, FLANGE, 6X18

Price €1.15
