WIRE HARNESS for CBR1000ST GRAND PRIX RED (R380) from 2024

WIRE HARNESS for CBR1000ST GRAND PRIX RED (R380) from 2024
Reference
Product name
#1 31600-MKN-D51

ASSY. RECTIFICATEUR-REGULATOR

Price €245.41
#2 31700-K98-E20

CONDENSER COMP

Price €32.04
#4 32606-KCW-J91

CAP, FAUX (2P) (ROUGE)

Price €15.30
#5 38201-MKR-DH1

COVER, FUSE BOX

Price €10.30
#6 38221-SNA-A31

FUSIBLE OF LAME (7.5A)

Price €6.85
#7 38221-SNA-A41

FUSIBLE OF LAME (10A)

Price €6.85
#8 38221-SNA-A51

FUSIBLE OF LAME (15A)

Price €6.85
#9 38221-SNA-A81

FUSIBLE OF LAME (30A)

Price €6.85
#10 38235-SNA-A01

EXTRACTEUR, MINI FUSIBLE

Price €6.65
#11 38255-MKR-DH1

COVER, FUSE BOX

Price €39.44
#12 38501-MCS-G01 i

POWER RELAY COMP. (MICRO ISO 4P)

Price €21.71
#13 38501-MKR-D11

POWER RELAY COMP. (MICRO ISO 4P) (PANASONIC)

Price €23.18
#14 38506-KZZ-900

COVER, RELAY (2P)

Price €6.76
#15 38506-MCS-G00

SUSPENSION, RELAIS PUISSANCE

Price €16.68
#18 38770-MKR-DH3 i

PGM-FI UNIT

Price €2,368.39
#19 38790-MKR-DH3 i

PGM-TBW UNIT

Price €1,547.28
#20 38950-MKR-D11

CONTROL UNIT, BODY

Price €663.23
#21 39960-MKS-E01

ASSY. SENDER (3GYRO & 3G)

Price €924.28
#22 39963-MKF-D41

GASKET, MOUNTING SENSOR

Price €12.32
#23 61105-KEV-900

COLLAR, HORN SETTING

Price €3.28
#24 64535-MFJ-D00

SIDE COVER RUBBER

Price €7.43
#25 80106-MKR-DH0

COVER, ELECTRONIC CONTROL UNIT

Price €60.89
#26 83119-MG9-000

BAND OF FIXING OF VERROU

Price €8.26
#27 90020-GHB-690

BOLT, FLANGE, 6X28

Price €5.96
#28 90030-GHB-630

FLANGE BOLT, 6X14

Price €5.46
#29 90116-SP0-003

CLIP OF GASKET SEALING OF BUMPER

Price €3.36
#30 90117-MKF-D40

BOLT SPECIAL, 5X14

Price €6.46
#31 90130-KYJ-900

CYLINDRICAL HEAD SCREW, 6X22

Price €3.97
#32 90201-415-000

NUT OF CAP, 6MM

Price €7.06
#33 90439-MB0-000

WASHER, RR COVER GROMMET

Price €5.71
#34 90535-MKE-A00

WASHER, 61MM

Price €7.20
#35 90620-SB2-003 i

STRIPE OF ELECTRIC HARNESS

Price €14.64
#36 90650-KV6-003 i

STRIPE, CABLE 95MM

Price €9.46
#37 90683-SA0-003 i

CLIP OF HARNESS ELECTRIC, 25MM

Price €9.37
#38 91535-TA0-003

CLIP D'COUPLING (BROWN FONCE)

Price €11.84
#39 91771-MKG-D81

COUPLEUR, FICTICE (6P 025M)

Price €15.30
#40 94050-06000 i

FLANGE NUT, 6MM

Price €0.79
#3 32100-MKR-DF0

FAISCEAU ELECTRIQUE

Price €1,288.04
