WIRE HARNESS (CBR1000FH/FJ/FM) for CBR1000F PEARL CRYSTAL WHITE-A (NH193O) from 1988

WIRE HARNESS (CBR1000FH/FJ/FM) for CBR1000F PEARL CRYSTAL WHITE-A (NH193O) from 1988
Reference
Product name
#1 17959-MM5-000

CLIP, CABLE

Contact us
#2 30505-MM5-640

BRACKET, IGNITION COIL

Contact us
#3 30510-KT7-013

COIL COMP, IGNITION

Price €223.82
#4 30520-ML7-000

SPACER, IGNITION COIL

Price €8.63
#5 30751-MM5-020

CAP ASSY 1, HIGH TENSION

Price €70.32
Contact us
#6 30752-MM5-020

CAP ASSY 2, HIGH TENSION

Price €61.92
Contact us
#7 30753-MM5-020

CAP ASSY 3, HIGH TENSION

Price €61.92
Contact us
#8 30754-MM5-020

CAP ASSY 4, HIGH TENSION

Price €64.03
Contact us
#9 31700-124-003

RECTIFIER ASSY, SILICON (STANLEY)

Price €36.23
#9 31700-124-008

RECTIFIER ASSY, SILICON (SHINDENGEN)

Price €36.23
#10 32100-MM5-600

HARNESS, WIRE

Contact us
#11 32105-MM5-000

SUB HARNESS, IGNITION

Contact us
#12 32503-MM5-000

COVER, COUPLER

Contact us
#13 36037-657-000

GROMMET A, TUBE

Price €5.58
#14 38200-MM5-005

PLATE ASSY, FUSE (DAIICHI)

Contact us
#15 38235-SA5-004

PULLER, FUSE (DAIICHI)

Price €5.20
#16 84706-415-000

COLLAR

Price €6.53
#20 92101-060160A

BOLT, HEX, 6X16

Price €1.04
#18 92000-060204J

BOLT, HEX, 6X20

Price €1.78
#19 93891-0501207

SCREW-WASHER, 5X12

Price €0.86
#21 95701-0601200

BOLT, FLANGE, 6X12

Price €1.13
#22 98200-31000

FUSE, BLADE (10A)

Price €1.15
#23 98200-31500

FUSE, BLADE (15A)

Price €1.15
