OIL PUMP for CBF125N NOIR (NH1) from 2018

OIL PUMP for CBF125N NOIR (NH1) from 2018
Reference
Product name
#1 15021-436-000

ROTOR SET, OIL PUMP

Price €53.87
#4 90702-KFM-900 i

DOWEL PIN, 8X12

Price €3.97
#6 94540-06018

E-RING, 6MM

Price €3.25
#7 95701-0603500 i

BOLT, FLANGE, 6X35

Price €1.34
#8 96220-40238

ROLLER, 4X238

Price €0.64
#2 15100-KPP-860

PUMP ASSY, OIL

Price €59.62
#3 15133-KPP-860

GEAR, OIL PUMP DRIVEN (23T)

Price €24.01
#5 93301-050120J

BOLT, HEX, 5X12

Price €1.61
# 31200-KPP-T01

MOTOR ASSY, STARTER (MITSUBA)

Price €222.43
# 31201-KPT-A01 i

TERMINAL SET, BRUSH

Price €11.88
# 31201-KVS-J01

TERMINAL SET, BRUSH

Price €11.88
# 31204-KG8-004 i

SPRING, CARBON BRUSH

Price €7.32
# 31205-KTC-921

BOLT, SETTING

Price €3.25
# 31206-KPP-T01

HOLDER, BRUSH

Price €4.57
# 31207-MBE-008

RING

Price €8.32
# 90071-MB0-000 i

NUT-WASHER, 6MM

Price €6.12
# 91309-425-003 i

O-RING, 244X31 (ARAI)

Price €12.66
# 91320-MB0-000

O-RING, 4X2

Price €5.34
# 95701-0602500 i

BOLT, FLANGE, 6X25

Price €1.34
