SWINGARM for CBF125M SPORTS RED (R321) from 2011

SWINGARM for CBF125M SPORTS RED (R321) from 2011
Reference
Product name
#1 06406-KWF-P01 i

CHAIN KIT, DRIVE (428-118L) (16/42T)

Price €152.24
#2 40510-KWF-950

CASE, DRIVE CHAIN

Price €10.80
#3 40530-KWF-951

CHAIN, DRIVE (RK428KRO-118L)

Price €451.70
#4 40544-KWF-950 i

ADJUSTER COMP, R CHAIN

Price €6.43
#5 40546-KWF-950

CAP, SWINGARM END

Price €1.67
#6 43431-KWF-900

ARM, RR BRAKE STOPPER

Price €7.22
#7 52101-KWF-950

BOLT, SWINGARM PIVOT

Price €9.32
#8 52170-KWF-900

SLIDER, CHAIN

Price €7.70
#9 52200-KWF-950

SWINGARM SUB ASSY, RR

Price €190.81
#10 90111-KWF-900

BOLT, FLANGE, 6MM

Price €1.52
#11 90302-KBP-900

NUT SPECIAL, 6MM

Price €5.57
#12 90306-KTE-911 i

NUT, FLANGE SPECIAL, 12MM (SIMMONDS MARSHALL)

Price €8.11
#13 90320-747-000

NUT OF SPRING, 6MM

Price €2.92
#14 92812-10000 i

BOLT A OF BRAS OF BUTEE

Price €3.84
#15 94001-060000S i

NUT HEX., 6MM

Price €1.19
#16 94001-080000S i

NUT HEX., 8MM

Price €1.19
#17 94101-08000 i

WASHER PLATE, 8MM

Price €0.73
#18 94111-10000 i

WASHER ELASTIQUE, 10MM

Price €0.88
#19 94201-20150 i

SPLIT PIN, 2.0X15

Price €0.78
