WIRE HARNESS for CBF125M PEARL SIENA RED (R320) from 2013

WIRE HARNESS for CBF125M PEARL SIENA RED (R320) from 2013
Reference
Product name
#1 30510-KTY-D31

COIL COMP, IGNITION

Price €69.94
#2 30520-ML7-000

SPACER, IGNITION COIL

Price €8.63
#4 31600-KSP-861

RECTIFIER COMP, REGULATOR

Price €194.50
#5 31700-196-000

RECTIFIER COMP, SILICON

Price €43.91
#6 32100-KWF-D00

HARNESS, WIRE

Price €192.79
#7 32606-GEV-761

CAP, DUMMY (4P) (RED)

Price €10.15
#8 33714-KL3-620

RUBBER, TAILLIGHT BRACKET

Price €6.62
#9 35160-KWF-951

SENSOR ASSY, BANK ANGLE

Price €367.94
Contact us
#10 35162-MFA-D01

COLLAR

Price €10.30
#11 35163-MBZ-C50

GROMMET

Price €4.99
#12 38110-KWF-952

HORN COMP

Price €51.77
Contact us
#13 38117-KFE-701

COLLAR, HORN SETTING

Price €18.05
#14 38301-KPL-901

RELAY COMP, WINKER

Price €35.51
#15 38306-GE7-000

SUSPENSION, WINKER RELAY

Price €11.92
#16 38770-KWF-D02

PGM-FI UNIT

Price €446.89
#17 38771-KTW-900

CUSHION, PGM-FI UNIT

Price €4.79
#18 90628-750-000

CLIP (14MM)

Price €3.11
#19 90651-KV6-003

BAND, WIRE, 165MM (BLACK)

Price €7.72
#20 92101-060204J

BOLT, HEX, 6X20

Price €1.78
#22 93903-24320

SCREW, TAPPING, 4X12

Price €0.62
#23 95701-0601200

BOLT, FLANGE, 6X12

Price €1.13
#23 95702-0601200

BOLT, FLANGE, 6X12

Contact us
#24 95701-0602008

BOLT, FLANGE, 6X20

Price €1.13
#24 95702-0602008

BOLT, FLANGE, 6X20

Contact us
#25 98200-41000

FUSE, MINI (10A)

Price €1.22
#26 30700-KSP-B01

CAP ASSY, NOISE SUPPRESSOR

Price €12.82
#27 93401-0402508

BOLT-WASHER, 4X25

Price €0.78
