SWINGARM for CBF125M BLACK (NH1) from 2013

SWINGARM for CBF125M BLACK (NH1) from 2013
Reference
Product name
#1 06406-KWF-P01

CHAIN KIT, DRIVE (428-118L) (16/42T)

Price €147.80
#2 40510-KWF-950

CASE, DRIVE CHAIN

Price €50.60
#3 40530-KWF-951

CHAIN, DRIVE (RK428KRO-118L)

Price €220.27
#4 40544-KWF-950

ADJUSTER COMP, R CHAIN

Price €7.48
#5 40546-KWF-950

CAP, SWINGARM END

Price €15.13
#6 43431-KWF-900

ARM, RR BRAKE STOPPER

Price €7.69
#7 52101-KWF-950

BOLT, SWINGARM PIVOT

Price €25.76
#8 52170-KWF-900

SLIDER, CHAIN

Price €13.48
#9 52200-KWF-950

SWINGARM SUB ASSY, RR

Price €325.61
#10 90111-KWF-900

BOLT, FLANGE, 6MM

Price €1.57
#11 90302-KBP-900

NUT, SPECIAL, 6MM

Price €3.36
#12 90306-KTE-911

NUT, FLANGE SPECIAL, 12MM (SIMMONDS MARSHALL)

Price €7.40
#13 90320-747-000

NUT, SPRING, 6MM

Price €2.86
#14 92812-10000

BOLT A, STOPPER ARM

Price €3.77
#15 94001-060000S

NUT, HEX, 6MM

Price €1.16
#16 94001-080000S

NUT, HEX, 8MM

Price €1.16
#17 94101-08000

WASHER, PLAIN, 8MM

Price €0.72
#18 94111-10000

WASHER, SPRING, 10MM

Price €0.86
#19 94201-20150

PIN, SPLIT, 20X15

Price €0.77
