AIR CLEANER for CB500X CANDY CHROMOSPHERE RED (R381) from 2018

AIR CLEANER for CB500X CANDY CHROMOSPHERE RED (R381) from 2018
Reference
Product name
#1 15771-KV6-000

CLIP OF TUBE OF DRAIN OIL

Price €7.08
#2 17211-MJW-J00

ELEMENT, AIR CLEANER

Price €49.90
#3 17213-MGZ-D00

GASKET SEALING, FILTER A AIR

Price €3.28
#4 17214-MGZ-D00

GASKET SEALING OF COVER OF FILTER A AIR

Price €2.47
#5 17215-MGZ-D00

GASKET SEALING, BODY DU PAPILLON DES THROTTLE

Price €3.37
#6 17216-MGZ-D00

GASKET OF DUCT OF FILTER A AIR

Price €2.47
#7 17220-MGZ-D00

COVER OF FILTER A AIR

Price €28.46
#8 17225-MGZ-D00

ASSY. OF CASE SECONDAIRE, FILTER A AIR

Price €29.89
#9 17232-KYJ-900

BAND OF MOUNTING OF FILTER AIR

Price €3.28
#10 17240-MJW-J00

DUCT, AIR CLEANER

Price €10.93
#11 17245-MGZ-D01 i

LID SUB ASSY, AIR CLEANER

Price €20.42
#12 17251-MGZ-A00

FUNNEL, L AIR

Price €26.57
#13 17252-MGZ-A00

FUNNEL, R AIR

Price €26.57
#14 17253-MGZ-D00

AIR FUNNEL

Price €6.49
#15 17265-MGZ-D00

PIPE OF BREATHER

Price €8.76
#16 17366-428-670

PIPE A OF DRAINAGE

Price €15.47
#17 17370-382-870 i

PLUG OF PIPE OF BREATHER

Price €2.70
#18 17724-102-700

AUXILIARY TANK HOSE CLIP

Price €7.08
#19 32150-MGZ-J00

SUPPORT, HARNESS SECONDAIRE ENGINE

Price €5.00
#20 32207-MGZ-J00

STAY OF HARNESS OF FILS

Price €5.00
#21 83545-KCJ-690

SIDE COVER RUBBER

Price €3.96
#22 90538-KSH-900

SPECIAL WASHER, 6MM

Price €3.28
#23 90646-657-000

CALIPER OF HOSE AIR, 16MM

Price €9.10
#24 91406-MS8-000

SCHLAUCHKLAMMER (D145)

Price €8.72
#25 91508-MGP-D00

KEGELKOPFBOLT, 5MM

Price €10.69
#26 93893-0501208 i

SCREW A HEAD A WASHER, 5X12

Price €1.08
#27 93901-25320

SELF-TAPPING SCREW, 5X16

Price €0.78
#28 93903-25480

SELF-TAPPING SCREW, 5X20

Price €0.64
#29 96001-0602004

FLANGE BOLT, 6X20

Price €1.36
