WIRE HARNESS for CB1000R GRAPHITE BLACK (NHB01) from 2023

WIRE HARNESS for CB1000R GRAPHITE BLACK (NHB01) from 2023
Reference
Product name
#1 31600-MKN-D51

ASSY. RECTIFICATEUR-REGULATOR

Price €245.41
#2 31730-MAS-601 i

DIODENEINHEIT, DREIWEG (SUMITOMO)

Price €22.76
#3 32100-MKJ-E60

HARNESS ELECTRIC

Price €1,148.78
#4 33714-KL3-620

RUBBER OF SUPPORT OF REAR LIGHT

Price €7.60
#5 33715-GB0-900

BAND D'INSTALLATION OF REAR LIGHT

Price €6.67
#6 35160-MGS-D31

SENSOREINHEIT, BOESCHUNGSWINKEL

Price €314.98
#7 38110-KPP-T01

HORN COMP. (TOP)

Price €37.60
#8 38117-KFE-701 i

RING, ADJUSTMENT KLAXON

Price €3.28
#9 38221-SNA-A31

FUSIBLE OF LAME (7.5A)

Price €6.85
#10 38221-SNA-A41

FUSIBLE OF LAME (10A)

Price €6.85
#11 38221-SNA-A51

FUSIBLE OF LAME (15A)

Price €6.85
#13 38501-MCS-G01 i

POWER RELAY COMP. (MICRO ISO 4P)

Price €21.71
#14 38501-MEL-003 i

ASSY. RELAIS D'ENERGIE (MICRO ISO 4P)

Price €7.66
#15 38501-MKR-D11

POWER RELAY COMP. (MICRO ISO 4P) (PANASONIC)

Price €23.18
#16 38506-KZZ-900

COVER, RELAY (2P)

Price €6.76
#17 38506-MCS-G00

SUSPENSION, RELAIS PUISSANCE

Price €16.68
#18 38770-MKJ-E51

UNIT PGM-FI

Price €2,505.65
#19 38940-MKR-D11

CHARGEUR, USB (TYPE-C)

Price €115.32
#20 38941-MLA-A00

COVER, CHARGEUR USB (TYPE-C)

Price €19.22
#21 38942-MLA-A00

CAP, COVER CHARGEUR USB

Price €8.86
#22 38950-MKJ-E51

UNIT COMMANDE, BODY

Price €764.02
#23 39571-MKJ-F60

SUPPORT COMP. (USB)

Price €42.77
#24 50355-MKJ-D00

STAY, SENSOR D'ANGLE D'INCLINAISON TRANSVERSALE

Price €22.27
#25 84703-425-000 i

MOUNTING RUBBER, SCHLUSS- LICHT

Price €10.22
#26 90020-GHB-640

FLANGE BOLT, 6X16

Price €5.71
#27 90102-MKH-D00

SCREW TARAUDEUSE SPECIAL, 5X14

Price €7.36
#28 90308-MT8-000

NUT OF CAP, 6MM

Price €7.32
#29 90652-HC4-003 i

CLIP OF HARNESS

Price €8.45
#30 90690-MEF-800

CLIP OF HARNESS

Price €6.23
#31 90851-961-000

RUBBER OF MOUNTING OF REAR LIGHT

Price €13.60
#32 91535-TA0-003

CLIP D'COUPLING (BROWN FONCE)

Price €11.84
#33 91771-MKK-H11

CAP, FAUX (6P) (ROUGE)

Price €24.54
#34 94050-06080 i

FLANGE NUT, 6MM

Price €1.20
#35 94103-06800 i

WASHER PLATE, 6MM

Price €0.78
#36 95701-0601608 i

FLANGE BOLT, 6X16

Price €1.08
#37 95701-0601807 i

FLANGE BOLT, 6X18

Price €0.96
#38 96001-0602500 i

FLANGE BOLT, 6X25

Price €1.50
#12 38255-MKJ-E51

COVER COMP UPPER

Price €24.58
